WHEATON Vial Guide

13 / 32

11 Vial Guide
DWK Life Sciences | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 |
Cat. No. Size (mL) Mouth ID x OD (mm) Dia. x H Qty / Case Fits Rack
Clear Serum Vials
223683 2 7 x 13 15 x 32 144 868804
223684 3 7 x 13 17 x 38 144 868810
223685 5 13 x 20 22 x 40 144 868805
223686 10 13 x 20 24 x 50 144 —
223687 20 13 x 20 30.5 x 58 120 —
Amber Serum Vials
223693 2 7 x 13 15 x 32 144 868804
223695 5 13 x 20 22 x 40 144 868805
223696 10 13 x 20 24 x 50 144 —
Note: When selecting a rubber stopper or aluminum seal, match the mouth OD
dimension of the vial.
• 2 - 20mL size
• Clear vials manufactured from low extractable borosilicate glass
that conforms to USP Type I and ASTM E 438 Type I, Class A
requirements
• Amber glass conforms to USP Type I requirements to protect
light-sensitive samples
• Tubular design provides excellent clarity and dimensional
consistency from vial to vial
• Specially designed bottom radius adds strength for lyophilization
applications
• Lighter weight compared to molded bottles
• Shrink-wrapped modules reduce particulate contamination
• Autoclavable
Cat. No. Size (mL) Dia. x H (mm) Cap Finish Size Fits Rack Qty / Case
Vacule® Vial
651954* 4 17 x 45 15-425 868810 200
651905 5 22 x 40 22-350 868805 200
651907 10 22 x 55 22-350 868805 200
Cat. No. Description Qty/Pack Qty / Case
15-425 Screw Thread Caps and Stoppers for Cat. No. 651954
224100-080 Red Rubber Stopper 100 1000
W224100-093 Lyophilization Stopper, 2-Leg 100 1000
240209 Cap, Solid Top, Rubber Liner 200 200
W240509 Cap, Open Top, without Liner 200 200
22-350 Screw Thread Caps and Stoppers for Cat. No. 651905 and 651907
224100-172 Red Rubber Stoppers 100 1000
W224100-193 Lyophilization Stopper, 2-Leg 100 1000
W224100-202 Lyophilization Stopper, 3-Leg 100 1000
239853 Cap, Solid Top, without Liner 500 500
*Purchase closures separately
• Heavy wall construction designed for
lyophilization and
freeze-drying applications
• Screw threads eliminate use of crimp
seal
• Manufactured from WHEATON 33 low
extractable clear borosilicate glass that conforms to USP Type I and
ASTM E 438 Type I, Class A requirements
• Vacule vials have controlled ID, for accurate stopper fit
• Choice of solid or open top screw cap
• 651905 and 651907 are supplied with unlined black phenolic cap
Vacule® Vial
Serum Bottle, PVC Dropper Tip
• Create a dropper container using a crimp /
serum bottle with 20mm mouth OD
• Dropper tip is made from PVC with HDPE
closure
• Dispenses 40µL drop using water
Part. No. Description Dia. x H (mm) Qty / Case
224080 PVC Dropper Tip 23 x 44 100
Serum Tubing Vials
Serum Bottle
• Ideal for long and short term sample storage, lyophilization and
vaccine / injectable drug containers
• Fits most lyophilization applications
• Borosilicate glass conforms to USP Type I requirements
• Clear bottles manufactured from WHEATON 400 borosilicate molded
glass that conforms to USP Type I requirements
• Amber bottles manufactured from WHEATON 500 borosilicate glass
that conforms to USP Type I requirements
• Shrink-wrapped partitioned modules reduce breakage
Cat. No. Color Size (mL) Mouth ID x OD (mm) Dia. x H (mm) Fits Rack Qty / Case
W223712 Clear 2 7 x 13 15.6 x 36 868810 288
223738 Clear 5 13 x 20 23 x 47 868805 288
223760 Amber 5 13 x 20 23 x 47 868805 288
223739 Clear 10 13 x 20 25 x 54 868806 288
223761 Amber 10 13 x 20 25 x 54 868806 288
223742 Clear 20 13 x 20 32 x 58 — 288
223762 Amber 20 13 x 20 32 x 58 — 288
223743 Clear 30 13 x 20 37 x 63 — 288
223763 Amber 30 13 x 20 37 x 63 — 288
223745 Clear 50 13 x 20 43 x 73 — 288
223764 Amber 50 13 x 20 43 x 73 — 288
223746 Clear 60 13 x 20 41 x 91 — 144
223747 Clear 100 13 x 20 52 x 95 — 144
223766 Amber 100 13 x 20 52 x 95 — 144
223748 Clear 125 13 x 20 54 x 107 — 144
*Note: Select aluminum seal and stopper size by using the mouth OD dimension of the bottle or vial
