WHEATON Vial Guide

20 / 32

Vial Guide 18
DWK Life Sciences | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 |
Culture Vial
• Culture vials feature deep-skirted screw caps to allow safer, more
dependable handling when working with infectious materials
• Vials are manufactured from WHEATON 33 low
extractable borosilicate glass that conforms to
USP Type I and ASTM E 438 Type I, Class A
requirements
• Pre-attached deep skirted solid-top black
phenolic screw cap with 14B rubber liner
• Autoclavable
• Vials packaged in corrugated trays with partitions
• Use M-T Vial File® (Cat. No. 228780) for storing
4mL vials and (Cat. No. W228790) for storing 8mL vials
Cat. No. Size (mL) *Dia. x H (mm) Cap Size Qty / Case
225142 4 15 x 51 13-415 144
225144 8 17 x 70 15-415 144
225145 12 19 x 72 15-415 144
*Measurement taken with cap attached.
Omni-Vial®, Polypropylene
• 4mL polypropylene vial for wide variety of lab applications
• Press-fit cap made from polypropylene
• Vials and caps are packed separately in two polybags
containing 500 each
• Vial can be autoclaved for 15 minutes at 121°C at 15 psi
Cat. No. Size (mL) Vial & Cap Material Liner Material Dia. x H (mm) Qty / Case
225402 4 Polypropylene Linerless 13 x 57 500
• Select from glass or HDPE
• Glass vials made from WHEATON 180 low
potassium borosilicate glass that conforms
to ASTM E 438 Type I, Class A and USP Type
I requirements
• Background counts are consistent and low
in glass vials; ultraviolet transmission is
high
• HDPE vials are economical choice for
scintillation counting
• Caps packaged separately
• For additional organization of your vials use the WHEATON Vial Rack
868810
Glass HDPE
Cap Liner Cap Dia. x H Qty/
Cat. No. Size (mL) Material Material Size (mm) Case
Glass
986491 6 Urea Metal Foil / Pulp 13-425 17 x 58 1000
986492 6 Urea Metal Foil / Pulp 15-425 17 x 58 1000
HDPE
986644 6 Polypropylene Linerless 18mm 17 x 57 1000
986645 6 Polypropylene Linerless 18mm 17 x 57 2000
Sampule® Vials
• Ideal for use in water sampling according to
EPA 40 CFR 136, “Guidelines for Establishing
Test Procedures for the Analysis of
Pollutants”
• Clear vials manufactured from WHEATON
33 low extractable borosilicate glass
that conforms to USP Type I and ASTM E 438 Type I, Class A
requirements
• Amber vials manufactured from WHEATON 320 amber glass that
conforms to USP Type I requirements for light transmission to
protect light-sensitive products
• PTFE faced silicone lined caps attached to vials
• Vials packaged in convenient trays for ease of use
Cat. No. Size (mL) Size (dr) *Dia. x H (mm) Cap Size Qty / Case
Clear Vial with Open Top Black Phenolic Cap
225310 40 10 28 x 98 24-400 72
Amber Vial with Open Top White Polypropylene Cap
225315 40 10 28 x 98 24-400 72
*Measurement taken with cap attached.
Replacement Screw Caps & Septa
Cat. No. Description Cap Size Qty / Case
W240518 Black Phenolic Open Top Screw Cap w/o Septa 24-400 200
W224600 White Glass-Filled Open Top Polypropylene Cap
with Bonded 5 mils PTFE / 120 mils Silicone Septa 24-400 200
Vials for Environmental Analysis
• Provided with open top white polypropylene
PTFE faced silicone lined cap
• Septa of 5 mils of PTFE facing 120 mils of
silicone is bonded to cap
Cat. No. Size (mL) Size (dr) Dia. x H (mm) (cap on) Cap Size Qty / Case
Clear
W224609 20 5 28 x 60 24-400 72
W224610 25 6.25 28 x 73 24-400 72
W241503 40 10 28 x 98 24-400 72
Amber
W224612 20 5 28 x 60 24-400 72
W224614 40 10 28 x 98 24-400 72
Dilution Vial
• Vial is marked with a blue line at the 3mL level
• Vials are manufactured from WHEATON 33 low
extractable borosilicate glass that conforms to USP
Type I and ASTM E 438 Type I, Class A requirements
• Pre-attached solid-top black phenolic screw cap with
14B rubber liner
• Autoclavable
• Vials are packaged in corrugated trays with partitions
• Use M-T Vial File® (Cat. No. 228780) for storing vials
Cat. No. Size (mL) *Dia. x H (mm) Cap Size Qty / Case
225002 4 15 x 48 13-425 144
*Measurement taken with cap attached.
EPA Vial, 40mL
