Vial Guide
DWK Life Sciences
| 800.225.1437 (U.S. & Canada Only) | 856.825.1100 |
www.DWK-LifeSciences.comSingleScan™ Bar Code Reader
•
Plug and play design enables easy set up
with
no software installation required
•
USB interface allows easy connection
to computer
•
Reads 1D linear bar codes and 2D Data Matrix
bar codes on any vial or ampule
•
Inputs decoded bar code ID into any software
application where curser is placed
Cat. No.
Description
Qty
W986000
SingleScan™ Bar Code Reader
1
•
2D Data Matrix Bar Code Reader
•
Works with WHEATON KeepIT®
Boxes and WHEATON CryoELITE®
Cryogenic Vials and Cryule®
Ampules as well as WHEATON
E-Z Microtubes
•
Flexible software integration
•
Integrated frost reduction system allows multiple racks to be read
•
Capable of reading bar codes from wide range of manufacturers and
label printers
PluraScan™ Bar Code Reader
Cat. No.
Description
Qty
W986010
PluraScan™ Bar Code Reader
1
WHEATON Scanners Technical Information
SingleScan™
PluraScan™
Code Formats
1D
Linear
—
2D Data Matrix
ISO 16022
Square | Rectangular Format
ECC 200
0-20 Grid Sizes
White on Black | Black on
White
Numeric
Alphanumeric
Sensor Type
1.3 million pixel CMOS
sensor
CCD Image Sensor
Light Source
Class 2M visible laser diode
at 630nm
CCFL (Cold Cathode
Fluorescent Light
Source)
Dimensions (W x D x H)
61mm x 167mm x 41.2mm 75cm x 50cm x 30cm
Power
USB Hub (5V)
AC 100 to 240V,
+10%/-10%,
Less than 8W
User Interface
Keyboard Wedge
WHEATON GUI,
including Windows®
operating system TCP
/ IP, ODBC
Cable Interface
USB
USB2.0 | USB 1.1
(B Type)
Operating System
Factory configured for
Windows® operating
systems compatibility.
Also compatible with non-
windows operating systems
Windows®7, 2000, XP
Ambient Operating Tem-
perature
5 to 50°C
Storage Temperature
-20 to 65°C
Operating Humidity
(Non-condensing) 5 to 95°C
Cat. No.
Description
Sterile Qty / Case
W985881
2D Data Matrix Bar Code Bottom Insert No
500
2D Data Matrix Bar Code Bottom Insert
•
When purchasing WHEATON CryoELITE® freestanding vials, you can
purchase an optional 2D Data Matrix Bar Code Insert that allows for
immediate bar coding of your samples. The insert can also be applied
to the vial at a future date, which eliminates jeopardizing the integrity
of your sample by transferring it to another vial
•
2D Data Matrix Bar Code Insert press fits and locks into place in
bottom of vial
