Vial Guide
DWK Life Sciences
| 800.225.1437 (U.S. & Canada Only) | 856.825.1100 |
www.DWK-LifeSciences.comLiner Material
Description
Applications
Foamed Polyethylene
(PE Foam)
A one piece, three ply coextruded liner consisting of both
foamed and solid LDPE. The foam core is sandwiched with
solid clear PE.
General Purpose: Broad applications base. Good chemical resistance to acids,
alkalis, solvents, alcohols, oils, household cosmetics and aqueous products.
Poor for hydrocarbon solvents. Liner provides tight seal.
Pulp / Metal Foil
Aluminum foil bonded to pulp board.
Good barrier properties and resistance to hydrocarbons, oils, ketones and
alcohols. Not good for acids or alkalis.
Polyethylene Cone
(PE Cone)
Manufactured from polyethylene (LDPE). The unique cone
design provides a wedge type seal that not only seals across
the top but also across the inside diameter.
Unique problem solving type of liner. This liner is stress crack resistant and
offers superior torque retention and excellent sealing characteristics. It is
recommended that this liner be tested prior to use for leak seal.
Note: Closures and liners are designed for a variety of applications. Product performance can vary depending on conditions. It is recommended that proper tests
be performed to determine the best liner for the application.
Cap Liner Guide
Glass
•
Made from WHEATON 180 low potassium borosilicate glass
that conforms to USP Type I and ASTM E 438 Type I, Class A
requirements
•
Background counts are consistent and low, ultraviolet
transmission is high
PET
•
Vials offer low permeability to solvents and minimal background
counts
•
Clarity of glass with the safety of plastic
•
Vials can be safely incinerated; no harmful gas is generated
Select from Glass, HDPE and PET Vials
•
Packaged in 5 utility trays with each partition tray holding
100 vials
•
Utility trays serve as a way to store your samples
•
For additional organization of your vials, use the
WHEATON Vial Rack 868806 or M-T Vial File® W228792
•
Cases with 1000 vials are packed in a single plastic bag
with caps in a separate bag
HDPE
•
Made from high density polyethylene with lightweight walls for
increased counting efficiency
•
Manufactured to precise tolerances to avoid jamming
