Sub Surface Grab Sampler® IIl
■ Use when sampling hazardous and corrosive
materials, as well as wastewater
■ Chemically resistant stainless steel and
polypropylene construction
■ Wide mouth accepts light sludges and slurries
■ The Grab Sampler® III fits wide-mouth bottles
with a 70-400 screw thread finish
■ A displacement plunger allows the collection of
samples in a 1000mL bottle
with approximately 1 inch of head space between the sample and the underside
of the bottle closure
■ Safety-coated 1000mL soda-lime glass bottle and a green urea cap with a
PTFE liner is included
■ To use it, you pull a cable that lifts a spring-loaded plunger, allowing liquid to
enter through four 5/8” x 1-1/2” slots
■ Release the cable when the bottle is full to reset the plunger
Cat. No. Description Qty / Case
990470 Sub Surface Grab Sampler® III 1
216641 Safety Coated Sample Bottle, 32 oz., 70-400 (without cap) 12
239244 Polypropylene Replacement Cap, 70-400, with PTFE Liner 48
E-Z Sampler®
■ Ideal for sampling unknowns from open-top drums and tanks
■ Manufactured from chemically
resistant polypropylene
■ The E-Z Sampler® has a 39” (100cm) head/shaft assembly and
is supplied with a 125mL borosilicate glass bottle with a PTFE
lined cap
■ Filling ports are located above the bottle to ensure that it is
completely filled to reduce the possibility of air entrapment
■ Bottle has a 33-430 screw thread finish
Cat. No. Description Qty / Case
885020 Complete Unit with Bottle 1
885025 125mL Bottle, with Cap 12
240480 Replacement Cap 100
> 104 Environmental
Sub Surface Grab Sampler® I
■ Ideal for sampling from spillways, docks and
other sub surfaces
■ No need to physically enter the sample area
■ Eliminates surface contamination
■ Helps meet EPA requirements for water and
wastewater sampling
■ Lightweight construction
■ Constructed of 72” x 3/4” (183 x 2cm) square
aluminum tubing with a golden anodine finish
■ Provided with a 1000mL narrow-mouth
borosilicate glass sample bottle with a PTFE-
lined cap and clamps for large and small bottles
Cat. No. Description Qty / Case
990250 Sub Surface Grab Sampler® I 1
990477 Replacement Sample Bottle, 1000mL, 38-430 1
240481 Black Phenolic Replacement Cap, 38-430, with PTFE Liner 100
Sub Surface Grab Sampler® II
■ Excellent for accessing fluid flow in deep manholes and
hard to reach sub-surface sampling areas
■ Helps meet EPA requirements for water and waste
water sampling
■ Available in lengths up to 18’ (5.5m)
■ Each sampler consists of an inert polypropylene head
with stainless steel fittings and an aluminum pole
assembly with a golden alodine finish
■ Provided with a 1000mL narrow-mouth borosilicate
glass sample bottle with a PTFE-lined cap
■ To use it, screw a sample bottle into the head and lower to the desired depth
■ Pull the cable at the top of the handle which will lift a spring-loaded plunger from
the bottle opening, allowing liquid to enter through four 5/8” diameter holes
■ Release the cable when the bottle is full to reset the plunger
Cat. No. Description Qty / Case
990350 6’ (183cm) Sub Surface Grab Sampler® II 1
990400 12’ (366cm) Sub Surface Grab Sampler® II 1
990450 18’ (549cm) Sub Surface Grab Sampler® II 1
990477 Replacement Sample Bottle, 1000mL, 38-430 1
240481 Black Phenolic Replacement Cap, 38-430, with PTFE Liner 100
Sample Bottle, Narrow Mouth
■ For use with Sub Surface Grab
Sampler® I & II
■ 1000mL narrow mouth borosilicate glass bottle
■ 38-430 screw cap with PTFE liner
■ Autoclavable
■ The bottle has a hand grip for easy handling
Cat. No. Description Qty / Case
990477 1000mL Bottle with Cap 1
Sample Bottle, Wide Mouth
■ For use with Sub Surface Grab Sampler® III
■ 1000mL wide mouth borosilicate glass bottle
■ 70-400 screw cap with PTFE liner
■ Autoclavable
■ These wide mouth sample bottles can be
repeatedly autoclaved and come with PTFE-
lined caps
Cat. No. Description Qty / Case
990476 1000mL Bottle with Cap 1
