WHEATON
800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
www.wheaton.com> 120
Performance and Ordering Information
Calibra
®
digital
822 Micro / 832 Macro Pipettes
The combination of instant volume adjustment, mechanical precision and ease of use
makes the Calibra
®
digital
a most reliable and robust micropipette line in the market.
Product Advantages
■
Winding-free, instant, volume adjustment
■
Long term performance and calibration stability
■
Robust, long lasting construction
■
Shock, UV light and autoclave resistant
■
Reliable user calibration
■
Minimal maintenance requirements
■
CE certified IVD 98/79 EEC
■
Interchangeable nozzle filter in all macro models
■
Three-year warranty
822 micro
0.2 - 2µL
1 - 10µL
2 - 20µL
10 - 100µL
20 - 200µL
100 - 1000µL
832 macro
0.2 - 2mL
1 - 10mL
Thin shaft shape helps reach contents
frommicrotubes and/or narrow containers.
The Calibra
®
provides convenient access
into those hard to reach places.
Fine Tuning Adjustment
Example: from 50 to 55.5µL in half a revolution of
the setting wheel in its “pulled” position.
Instant Volume Setting
Twin cam system fitted with pre-calibrated steps
providing for true digital volume entry and numerical
display. The dual incrementation allows fast volume
setting without tedious winding.
Key Volume Adjustment
Example: from 10 to 50µL in half a revolution of the
setting wheel placed in its normal position.
Inaccuracy (E%)
Imprecision (CV%)
Cat. No.
Volume
Division
Min. Vol.
Mid. Vol.
Max. Vol.
Min. Vol.
Mid. Vol.
Max. Vol.
Tip Style
Calibra
®
digital
822
851160
0.2 - 2µL
0.1µL
< ± 6.0 %
1)
< ± 4.0 % < ± 2.0 %
< 5.0 %
1)
< 3.3 % < 1.5 %
10µL
851162
1 - 10µL
0.05µL
< ± 2.5 % < ± 1.5 % < ± 1.0 %
< 2.0 % < 1.3 % < 0.5 %
10µL
851163
2 - 20µL
0.1µL
< ± 2.5 % < ± 1.5 % < ± 1.0 %
< 1.7 % < 1.1 % < 0.5 %
200µL
851164
10 - 100µL
0.5µL
< ± 1.5 % < ± 0.9 % < ± 0.8 %
< 1.0 % < 0.6 % < 0.2 %
200µL
851166
20 - 200µL
1.0µL
< ± 1.5 % < ± 0.9 % < ± 0.6 %
< 0.6 % < 0.4 % < 0.2 %
200µL
851168
100 - 1000µL
5.0µL
< ± 1.5 % < ± 0.6 % < ± 0.5 %
< 0.5 % < 0.4 % < 0.2 %
1000µL
Calibra
®
digital
832
851340
0.2 - 2mL
0.01mL
< ± 1.5 % < ± 1.0 % < ± 0.5 %
< 0.5 % < 0.3 % < 0.2 %
2mL
851345
1 - 10mL
0.1mL
< ± 1.5 % < ± 1.0 % < ± 0.5 %
< 0.3 % < 0.3 % < 0.15 %
10mL
Performance values obtained with double-distilled water at constant temperature (± 0.5°C) comprised between 20 and 25°C in accordance with ISO 8655.
1)
measured at 0.5µL
Liquid Handling
