WHEATON 2015 Lab Catalog

107 / 196

WHEATON 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
Oil Sample Bottle, Clear
■ Clear, Type III soda-lime glass
■ Bottles come with cork inserted
Cat. No. Capacity (oz) Capacity (mL)* Dia. x H (mm) Qty / Case
W216994 4 125 37 x 163 144
*Approximate capacity
> 106 Environmental
TCLP Extraction Bottle
Cap Liner
TCLP Extraction Bottle Cap
■ Use these bottles to determine if any of
40 contaminants are in waste material
■ Heavy-duty borosilicate bottles are used in
EPA methods 1310 Extraction Procedure,
1311 Toxicity Characteristic Leaching
Procedure (TCLP) and 1312 Synthetic
Precipitation Leaching Procedure (SPLP) for
those substances subject to regulation under
Subtitle C of the Resource Conservation and
Recovery Act (RCRA)
■ Bottles have GPI 100-400 thread finish
■ Pre-cleaned TCLP bottles are available as special order.
Contact WHEATON Customer Service for more information
Cat. No. Capacity (L) Description OD x Length (mm) Qty / Case
216711 2.2 Single-End Opening 110 x 325 1
216712 2.2 Double-End Opening 110 x 334 1
216731 3.2 Single-End Opening 110 x 450 1
■ 100-400mm polypropylene screw cap
■ For use with TCLP Extraction Bottles
■ Purchase liners separately
Cat. No. Description Qty / Case
240202 White heavy duty PP screw cap; resilient to mechanical and chemical attack 4
240203 White heavy duty PP screw cap with center hole
Use with Zitex ® Cap Liner (Cat. No. 240555) to self-vent the bottle 4
240204 White light duty PP screw cap with a shorter skirt 4
240202 240203 240204
■ For TCLP Extraction Bottles
■ Zitex® liner consist of a laminate that combines Zitex®, a porous form of PTFE
with unique venting properties, to a resilient foam backing
■ PTFE / Silicone liner consists of 0.005" PTFE bonded to 0.060" silicone and
provides excellent chemical resistance
Cat. No. Description For Cap Size (mm) Qty / Case
240555 Zitex® Cap Liner 100-400 4
240557 PTFE / Silicone Cap Liner 100-400 4
Imhoff Cone, Plastic
■ Designed for volumetric determination of
settleable solids
■ Cone is externally graduated from the plug
up to 1000mL
■ Imhoff Cone is manufactured from an acrylic
copolymer and includes a rubber plug and
polypropylene cap
■ Remove the leak-resistant screw cap and
plug to clean
■ Reference: Standard Methods for the Examination of Water and Wastewater, 21st
Edition (2005), Method 2540 F
■ 3 and 4-place Imhoff Cone Racks are sold separately and are constructed of
epoxy-coated, heavy-gauge steel to provide long life
Cat. No. Description Size (mL) Top Dia x Length (mm) Qty / Case
W990800 Imhoff Cone 1000 108 x 451 4
Imhoff Cone Racks
990760 3-Place Rack — — 1
990760-4 4-Place Rack — — 1
Drum Opener
■ Can be used with hazardous materials
■ Cast from lightweight, durable aluminum alloy and
features a quarter-turn opening action
■ Opens all 3/4” and 3” closures
Cat. No. Description Qty / Case
885295 Drum Opener 1
Scoop, Stainless Steel
■ Manufactured from 18/8 stainless steel
■ Ideal for sampling powders, slurries, soils, etc.
■ Dimensions: Overall length is 9-1/2” (24cm);
the bowl’s dimensions are
5 1/2” x 3” x 1 1/8” (14 x 7.6 x 2.9cm) 4oz
Cat. No. Description Qty / Case
885540 Scoop 4
