Acura
®
manual
810 Dilution Pipette
Air displacement pipette with two pre-calibrated steps allows subsequent pipetting of
1 and 0.1mL of the same liquid. Metal nozzle fits long straw tips to aspirate from narrow
or deep reservoirs (i.e. Stomacher
®
bags). Ideal alternative to the graduated glass
pipettes when performing serial 1:10 dilutions in bacteriology.
Product Advantages
■
Two pre-calibrated fixed volumes - no setting required
■
Smooth activation, excellent ergonomics
■
Interchangeable PE nozzle protection filter
■
Justip
™
system for height adjustment of tip ejector
■
Independent calibration for each volume
■
Easy maintenance, cleaning and disinfection
■
Fully autoclavable 121°C/250°F
■
Three-year warranty
810
1 + 0.1mL
Simple Operation
Depress plunger button in full, then release slowly to aspirate 1.1mL
Depress plunger button to first stop, thus dispensing 1mL in Petri dish
Depress plunger button to second stop, thus dispensing residual
0.1mL in next Petri dish
No Setting Required
Two fixed volumes within one plunger travel.
Innovative Dual Calibration
Both volumes of 1mL and 0.1mL can be calibrated independently from each other.
Calibration switch protected by seal sticker.
Justip
™
Ejector
Turn left or right to adjust ejector to straw tip position on the nozzle.
StrawTips
Made of high quality polypropylene. Specially designed for narrow vials and Stomacher
®
bags. Large diameter (4mm) prevents blocking by particles in suspension.
Cat. No.
Volumes
Inaccuracy (E%)
Imprecision (CV%)
851343*
1mL
< ± 0.5 %
< 0.4 %
0.1mL
< ± 2.0 %
< 2.5 %
Performance values obtained with double-distilled water at constant temperature (± 0.5°C)
comprised between 20 and 25°C in accordance with ISO 8655.
* Includes 10 Nozzle Protection Filters and one 1.1mL Straw Tip
Performance and Ordering Information - Instrument
Cat. No.
Description
Volume
Qty / Pack
851344
Straw Tips, Polypropylene, Sterile
1.1mL
4 x 25/pk
(L: 190mm, dia: 4mm)
W851348
Nozzle Protection Filter, PE Material
100
Ordering Information - Accessories
Liquid Handling
