WHEATON 2015 Lab Catalog

137 / 196

WHEATON 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
Liquid Handling
Calibrex™ digital Accessories
Work Stations
Dispenser Stability
Stand holds dispenser up to 50mL,
when screwed on small-size bottles.
Bulk Container Aspiration
Work station facilitates liquid intake
from drum or other remote container
(< 10m distance, < 2m elevation).
Extension Tubing
Autoclavable PTFE delivery Jet-Pen™ and extension tubing help dispense into vessels
with maximum comfort within a 60cm distance. Fits Calibrex™ Model 520 dispenser up
to 20mL. Also fits Calibrex Models 525 / 530.
Feed Tubing
Each Calibrex™ digitaldispenser is supplied with one PTFE feed tubing. Spare feed
tubings are available either cut to the standard size, or uncut by the meter. The latter is
also recommended when aspirating from remote bulk containers.
Ordering Information
Cat. No. Description Qty / Pack
W832026 Stand for Calibrex 520 Dispensers* 1
W832028 Stand for remote liquid intake, Calibrex 520* 1
W832030 Stand for remote liquid intake, Calibrex 535, 530* 1
W844136 Stand for Calibrex 525, 530 Dispensers* 1
* Dispenser and feed tube not included, to be ordered separately
Cat. No. Description Length Inside Dia.
Extension and Replacement PTFE Tubing
844024 Ext. Tubing for Calibrex 520 Dispensers up to 20mL 600mm 2.2mm
W844149 Ext. Tubing for Calibrex 525/530 Dispensers, 2.5-25mL 600mm 2.2mm
W844150 Ext. Tubing for Calibrex 525/530 Dispensers,
5 - 50mL and 10 - 100mL 600mm 2.2mm
I051154 Replacement Feed Tubing, 520 All Sizes 300mm 5mm
W844124 Replacement Feed Tubing, 525 and 530 350mm 7mm
W844126 Replacement Feed Tubing, 525 and 530 1000mm 7mm
Cat. No. Shape Volume Screw Thread Size Qty / Case
Amber Soda-lime Glass
W832000 Square 100mL 32mm 1
844025 Square 250mL 32mm 1
W844028 Square 500mL 32mm 1
844029 Square 1000mL 45mm 1
844030 Round 2500mL 45mm 1
Amber Soda-lime Glass with Handle
W832004 Round 2500mL 45mm 1
Polyethylene Coated Amber Soda-lime Glass
844027 Square 500mL 32mm 1
W832006 Square 1000mL 45mm 1
W832008 Round 2500mL 45mm 1
Clear Borosilicate Glass with Graduations
W832010 Round 250mL 45mm 1
W832012 Round 500mL 45mm 1
W832014 Round 1000mL 45mm 1
W832016 Round 2000mL 45mm 1
Clear Pyrex® Glass with Connection Neck
844026 Round 500mL 32 mm 1
Polyethylene Bottle
W832018 Oblong 250mL 25mm 1
W832020 Oblong 500mL 25mm 1
W832022 Square 1000mL 32mm 1
W832024 Square 2500mL 45mm 1
Reagent Bottles
Bottle-Top Adapters
The 520 model have a 32mm base thread. They come along
with three Polypropylene bottle neck adapters in 28, 40,
45mm diameters (Model 520). These adapters and others
are available separately.
Cat. No. Fits Bottle Thread Size (mm) Qty / Case
Threaded, PP
W830000 22 1
W830002 25 1
844032 28 1
W830006 34 1
W830008 36 1
844035 38 1
W830010 40 1
844038 45 1
Threaded, PTFE
W830012 36 1
W830014 38 1
W830016 40 1
W830018 45 1
Cat. No. Fits Bottle Taper Size (mm) Qty / Case
Tapered, PP
W830020 19/26 1
W830022 24/29 1
W830024 29/32 1
W830026 45/40 1
Tapered, PTFE
W830029 19/26 1
W830031 24/29 1
W830032 29/32 1
Large selection of glass and Polyethylene reagent bottles,
each supplied with one screw cap. Perfectly adapted
with Calibrex™ bottle top dispensers. Corresponding neck
adapters supplied with the dispensers.

> 136

Delivery Jets
Cat. No. Description Qty / Pack
W844116 Standard Length (120cm) Delivery Jet
for 25mL Calibrex 525, 530 Dispensers 1
W844118 Standard Length (120cm) Delivery Jet
for 50 & 100mL Calibrex 525, 530 Dispensers 1
W844120 Extended Length (150cm) Delivery Jet
for 25mL Calibrex 525, 530 Dispensers 1
W844122 Extended Length (150cm) Delivery Jet
for 50 & 100mL Calibrex 525, 530 Dispensers 1
