Diazomethane Generator
With Standard Taper Clear-Seal™ Grease-Free Joints
■ Used to generate diazomethane and other gases for gas
chromatography, mass spectroscopy and NMR studies using
one millimole of Methylnitronitrosoguanidine (MNNG)
■ Features Clear-Seal™ grease-free joints that have never
been ground and does not require an “O” ring
■ Includes a plastic standard taper joint clamp, a 13-425
screw cap with cut-out top and a PTFE faced rubber liner
■ Manufactured from WHEATON 33 low extractable
borosilicate glass that conforms to ASTM E 438 Type I,
Class A requirements
■ Note: Please use a safety shield and efficient fume hood
when generating diazomethane or similar gases
Cat. No. Description Approx Height (mm) Qty / Case
281135 Diazomethane Generator, Complete 190 1
W240593 13mm PTFE Faced Butadiene Septa — 100
Diazomethane Generator
■ Used to generate diazomethane and other gases for gas
chromatography, mass spectroscopy and NMR studies
using one millimole of Methylnitronitrosoguanidine (MNNG)
■ Includes an “O” ring clamp, a 13-425 screw cap with a
cut-out top and a PTFE faced rubber liner
■ Manufactured from WHEATON 33 low extractable
borosilicate glass that conforms to ASTM E 438 Type I,
Class A requirements
■ Note: Please use a safety shield and efficient fume hood
when generating diazomethane or similar gases
Cat. No. Description Approx Height (mm) Qty / Case
281155 Diazomethane Generator, Complete 200 1
281158 “O” ring for Cat. No. 281155 12
W240593 13mm PTFE Faced Butadiene Septa 100
Evaporative Concentrator, Kuderna-Danish
With Clear-Seal™ Joints
■ Designed for the concentration of trace amounts of analyte in an
organic solvent prior to analysis
■ Smooth Clear-Seal™ joints eliminate the need for grease, reducing
the possibility of contaminating the sample
■ Complete unit consists of 270mm three-ball Snyder column,
500mL flask and 10mL receiving vessel
■ Manufactured from WHEATON 33 low extractable borosilicate
glass that conforms to ASTM E 438 Type I,
Class A requirements
Cat. No. Description Qty / Case
297883 Kuderna-Danish Concentrator, Complete 1
Component Parts
384353 Snyder Column, 270mm, Three-Ball, with 24/40 Clear-Seal™ Joints 1
297825 500mL Flask, with 24/40 Top and 19/22 Bottom Clear-Seal™ Joints 1
297800 10mL Receiving Vessel, with 19/22 Clear-Seal Joint
(Graduated 0-1 x 0.1mL; 2-10 x 0.5mL) 1
Micro Soxhlet Extraction Apparatus
With the WHEATON Connection ®
■ Used for continuous extraction of analytes from a solid into an
organic solvent
■ WHEATON Connection® eliminates the need for hooks, springs and
clamps common to standard ground joint designs
■ As the flask containing the solvent is heated, vapors rise in the
larger outside tube, enter the water-cooled condenser, and liquate
■ When the liquid level in the extractor reaches the top of the bent
tube, siphoning action returns the extract-enriched solvent
to the flask
■ Wetted parts are manufactured from either WHEATON 33 low
extractable borosilicate glass that conforms to ASTM E 438 Type I,
Class A requirements or PTFE
Cat. No. Description Qty / Case
415500 Micro Soxhlet Extractor, Complete 1
Component Parts
415501 85mm Condenser, 24-400 Screw Thread on Bottom
and 13-425 Screw Thread on Side 1
415502 Extractor, 24-400 Screw Thread on Top
and 20-400 Screw Thread on Bottom 1
125486 WHEATON Connection® 20-400 to 20-400 6
125504 WHEATON Connection® 24-400 to 24-400 6
635134 25mL Erlenmeyer Flask, 20-400 Screw Thread 1
962515 Hose Connector, 13-425 6
W416788 Extraction Thimble, Glass, 15 x 60mm, 170-220μm Porosity 1
Soxhlet Extraction Apparatus
With Standard Taper Ground Joints
■ Used for continuous extraction of analytes from a solid into an
organic solvent
■ As the flask containing the solvent is heated, vapors rise in the
larger outside tube, enter the water-cooled condenser and liquate
■ When the liquid level in the extractor reaches the top of the bent
tube, siphoning action returns the extract-enriched solvent
to the flask
■ Wetted parts are manufactured from WHEATON 33 low extractable
borosilicate glass that conforms to ASTM E 438 Type I, Class A
requirements
Cat. No. Description Qty / Case
416000 125mL Soxhlet Extractor, Complete 1
416005 250mL Soxhlet Extractor, Complete 1
416010 500mL Soxhlet Extractor, Complete 1
Component Parts
415000 190mm Extractor with 24/40 bottom inner joint and 34/45 top outer joint 1
415005 205mm Extractor with 24/40 bottom inner joint and 45/50 top outer joint 1
415010 250mm Extractor with 24/40 bottom inner joint and 55/50 top outer joint 1
334003 Allihn Reflux Condenser, 34/45 1
334014 Allihn Reflux Condenser, 45/50 1
334025 Allihn Reflux Condenser, 55/50 1
428126 Flat-Bottom Flask, 125mL, 24/40 1
428146 Flat-Bottom Flask, 250mL, 24/40 1
428164 Flat-Bottom Flask, 500mL, 24/40 1
