WHEATON
800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
www.wheaton.comDesiccators
■
WHEATON Dry-Seal
™
vacuum desiccators come complete with desiccator jar,
cover, sleeve valve, silicone sealing ring and aluminum plate
■
Place your sample inside the desiccator and apply vacuum to the side arm
sleeve valve
■
The cover of the dessicator jar has a molded arrow on the top for alignment to
the open position
■
Simply turn the sleeve valve to close the desiccator
■
To open the cover, simply turn sleeve valve to the open position
■
Once equilibrated, the cover will easily lift off
■
The desiccator is manufactured from soda-lime glass
■
To prevent freezing and increase performance, lubricating the standard taper
sleeve valve with silicone-based vacuum grease is recommended
■
A 1/4” to 3/8” vacuum hose (not included) is used to connect the desiccator to
vacuum or gas
■
Manufactured from rugged, heavy soda-lime glass
■
Lift off cover for storage above flange
■
Silicone sealing ring for greaseless sealing
■
Maximum vacuum of 27” Hg (914 hPa)
■
Temperature range: 15°C to 80°C
Cat. No.
Description
Qty / Case
Component Parts for WHEATON Dry-Seal
™
170mm Vacuum Desiccator
W365825
Jar
1
W365895
Cover, without Sleeve Valve
1
W366025
Silicone Sealing Ring
1
W365915
Silicone Sleeve Valve Retaining Ring
6
W366045
Aluminum Plate
1
W365905
Sleeve Valve
1
Component Parts for WHEATON Dry-Seal
™
250mm Vacuum Desiccator
W365827
Jar
1
W365897
Cover, without Sleeve Valve
1
W366027
Silicone Sealing Ring
1
W365915
Silicone Sleeve Valve Retaining Ring
6
W366047
Aluminum Plate
1
W365905
Sleeve Valve
1
Cat. No.
Opening Size (mm)
Plate Size (mm)
Qty / Case
W365885
170
147
1
W365887
250
234
1
■
Packs are designed for use in all desiccators including the WHEATON Dry-Seal
™
opening vacuum desiccators
■
Desiccant pack is placed in the bottom of the desiccator under the aluminum
plate to preserve an anhydrous atmosphere within the desiccator
■
Desiccant is totally enclosed in fabric and perforated plastic for a dust-free
environment
■
Supplied in a sealed foil package
■
Reactivation of the desiccant is required when pack turns from blue to pink
■
To reactivate simply place the entire packet with perforated side down into
vented oven and heat for approximately three hours at 150°C or until the
desiccant returns to its original blue color
Cat. No.
To Use With
Qty / Case
366074
W365885
1
366076
W365887
1
W365885
W365887
366074
366076
> 74
Chemistry Glassware
Dry-Seal
™
VacuumDesiccators
Desiccant Packs
