WHEATON

800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |

www.wheaton.com

Bottles manufactured from soda-lime glass that conforms to USP Type III

requirements

Available in clear glass or amber glass for light sensitive samples

Narrow mouth bottles are ideal for liquids

Wide mouth bottles are ideal for dry and viscous samples

Valumetric

bottles are for measuring while you sample

White polypropylene or black phenolic screw caps

Screw caps are pre-attached to the containers or are available separately

Choice of cap liners: PTFE faced foamed polyethylene liner, poly-vinyl liner, rubber

liner, PTFE faced rubber, or PE cone liner

Tamper Evident Seal / HAZCOM Label provided in each case of bottles with the

exception of bulk packs

Cap Liner Specifications

Material

Description

Applications

Pulp / Poly-Vinyl

General purpose: Suitable for wide range of applications. Chemical

resistance: Good for mild acids, alkalis, solvents, alcohols, oils and

aqueous products. Poor for active hydrocarbons and bleaches.

One mil poly-vinyl film bonded to one mil HDPE on a #30 white

pulp paper backing. Superior to plain pulp paper because it

provides an excellent moisture barrier.

Typical applications: analytical lab samples, high purity chemicals, strong

acids, solvents. Excellent for environmental samples, pharmaceuticals

and diagnostic reagents.

PTFE faced foamed polyethylene liner that offers the excellent

chemical resistance of PTFE with the compressibility and

sealing properties of polyethylene foam.

PTFE Faced Foamed

Polyethylene

Unique problem solving type of liner. This liner is stress crack resistant

and offers superior torque retention and excellent sealing characteristics.

It is recommended that this liner be tested prior to use for leak seal.

Manufactured from polyethylene (LDPE). The unique cone

design provides a wedge type seal that not only seals across

the top but also across the inside diameter.

PE Cone

Excellent properties of resilience, resistant to moisture vapor.

Satisfactory for most moderate chemicals. Not good for oils, strong acids

and hydrocarbons. Autoclavable.

The 14B white rubber lining material consists of homogeneous

sulfur cured styrene-butadiene rubber. FDA Status complies with

21CFR 177.26, “Rubber articles intended for repeated use.”

Styrene-Butadiene

Rubber (14B)

Designed for the ultimate in product safety. PTFE provides totally inert

inner seal and surface facing the sample or product. Autoclavable.

The white rubber / 0.005" PTFE liner consists of virign PTFE

bonded to the white sulfur cured styrene-butadiene rubber.

Complies with the FDA 21CFR 177.1550.

PTFE Faced Rubber

> 12

Glass Bottles

General Purpose Glass Bottles
