8 / 196
WHEATON
800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
www.wheaton.comClear Ampule, Pre-scored
■
Pre-scored to eliminate filing
■
Made from low extractable borosilicate glass
that conforms to USP Type I and ASTM E 438 Type I,
Class A requirements
■
Stems can be pull or tip sealed
Cat. No.
Size (mL)
Dia. x H (mm)
Qty / Case
176772
1
10.5 x 67
144
176776
2
12 x 75
144
176779
5
16.5 x 84
144
176780
10
19 x 107
144
176782
20
22.5 x 130
144
Ampule, One Point Break
■
One point break to eliminate filing
■
Made from low extractable borosilicate glass
that conforms to USP Type I requirements
■
Stems can be pull or tip sealed
Cat. No.
Size (mL)
Dia. x H (mm)
Qty / Case
W176784A
50
27.5 x 170
100
Amber Ampule, Pre-scored
■
Pre-scored to eliminate filing
■
Made from amber borosilicate glass that conforms to
USP Type I requirements for light transmission to protect
light-sensitive products
■
Stems can be pull or tip sealed
Cat. No.
Size (mL)
Dia. x H (mm)
Qty / Case
176792
1
10.5 x 67
144
176796
2
12 x 75
144
176799
5
16.5 x 84
144
Ampule, Standard
■
Commonly used for packaging certified standards
■
Consistent with low background counts
■
Made from low potassium borosilicate glass
that conforms to USP Type I and ASTM E 438 Type I,
Class A requirements
Cat. No.
Size (mL)
Dia. x H (mm)
Qty / Case
176759
7
17 x 95
25
176762
20
28 x 100
25
Cryule
®
Cryogenic Ampule
■
For biological sample preservation in glass
■
Allows for storage at low temperatures
■
Made from low extractable borosilicate glass that conforms
to USP Type I and ASTM E 438 Type I, Class A requirements
■
Can be used in the vapor phase of liquid nitrogen
■
Special design allows for storage at low temperatures
as well as rapid thawing
Cat. No.
Size (mL)
Dia. x H (mm)
*OD at Top (mm)
Qty / Case
651463
1.2
11.8 x 58
5
144
651466
2
11.5 x 70
5
144
W651469
5
16.5 x 98
8
293
* Approximate OD
Cryule
®
Cryogenic Ampule, Pre-scored
■
For biological sample preservation in glass
■
Pre-scored to eliminate filing
■
Allows for storage at low temperatures
■
Made from low extractable borosilicate glass that conforms
to USP Type I and ASTM E 438 Type I, Class A requirements
■
Can be used in the vapor phase of liquid nitrogen
■
Special design allows for storage at low temperatures
as well as rapid thawing
Cat. No.
Size (mL)
Dia. x H (mm)
*OD at Top (mm)
Qty / Case
651483
1.2
11.8 x 58
5
144
651486
2
11.5 x 70
5
144
* Approximate OD
Vacule
®
Lyophilization Ampule
■
Ideal for small volume lyophilization samples
■
Made from low extractable borosilicate glass that conforms to USP
Type I and ASTM E 438 Type I, Class A requirements
■
Heat or stopper sealed
■
To stopper seal, use WHEATON Stopper W651450
Cat. No.
Description
Dia. x H (mm)
*OD at Top (mm) Qty / Case
W651446
2mL Vacule
12 x 86
10
567
W651450
11mm Gray Butyl Stopper
—
—
144
* Approximate OD
Vacule
®
Lyophilization Ampule, Pre-scored
■
Ideal for small volume lyophilization samples
■
Pre-scored for easy opening
■
Made from low extractable borosilicate glass that conforms
to USP Type I and ASTM E 438 Type I, Class A requirements
■
Heat sealed only
Cat. No.
Size (mL)
Dia. x H (mm)
*OD at Top (mm)
Qty / Case
651502
1
10 x 108
10
144
W651506
2
11.8 x 122
11.75
567
* Approximate OD
> 7
Ampules
