Liquid Handling
Performance All Models
Imprecision (CV%)
Volume Min. Vol. Mid. Vol Max. Vol.
0.025 - 0.3mL < 1.8 %1) < 1.2 % < 0.5 %
0.1 - 0.5mL < 1.2 % < 0.9 % < 0.4 %
0.1 - 1mL < 0.7 % < 0.6 % < 0.4 %
0.3 - 2mL < 0.6 % < 0.5 % < 0.4 %
0.5 - 5mL < 0.5 % < 0.4 % < 0.2 %
1 - 10mL < 0.5 % < 0.4 % < 0.2 %
5 - 20mL < 0.5 % < 0.4 % < 0.4 %
Tests performed with double-distilled water, using stainless steel cannula (1.2x50 mm), at constant
working speed.1) measured at 0.075mL
Liquid Path Materials (For Chemical Resistance)
Parts Basic / Classic Models Premium Models
Feed tubing Silicone Silicone
Barrel Borosilicate glass Borosilicate glass
Washer, barrel FPM (Fluoroelastomer) FPM (Fluoroelastomer)
Plunger Stainless steel DIN 304 Stainless steel DIN 316L
Valve system Ni-Cr Brass Stainless steel DIN 316L
Washer, valve PTFE PTFE
Spring and balls, valve Stainless steel, DIN 304 Stainless steel, DIN 304
Sinker, feed cannula Ni-Cr Brass Ni-Cr Brass
Dosys™ Laboratory Syringes
From the basic unit to the corrosion resistant model, the laboratory dedicated syringe
line offers precision instruments you can trust. Intended for safe and reliable liquid
distribution, the selection of pistol grip and two ring instruments comes in a wide volume
range.
Product Advantages
■ Optimal hand balance and ergonomics
■ Fast and reliable volume setting
■ Excellent reproducibility
■ Plunger tightness without O-ring
■ High chemical resistance
■ Fully autoclavable at 121°C/250°F
■ One-year warranty
Two Ring Handle
162
163
164
Pistol Grip Handle
172
173
174
Syringe Stand
Stand holds syringe in ready-to-use position. Easy to clean material. Autoclavable.
(Cat. No. W855008)
Simple, Natural Movements
Both pistol grip and two-ring handles fit any hand in a comfortable way. Activation
performed with limited effort for efficient work even during long dispensing series.
Volume Selection - Reliable Reproducibility
Volume is set within seconds. It will not vary while activating the syringe, thanks to
the safety-locking nut on the micrometric screw. Dose by dose reproducibility (CV) is
excellent, as witnessed by performance figures.
Plunger Tightness without O-ring
Smooth plunger travel and tightness achieved through high precision stainless steel
plunger and grounded glass barrel. No O-ring to mess with or replace.
Glass Protection
Interchangeable glass barrel is protected by a PVC sleeve (not autoclavable) to prevent
breakage.
Few Part Assembly - Low Maintenance
The automatic syringes are made of only six main parts, easy to disassemble. Fast
access to all elements allows rapid and efficient cleaning. Spares are available at
reasonable costs.
