137 / 196
WHEATON
800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
www.wheaton.comLiquid Handling
Calibrex
™
digital
Accessories
Work Stations
Dispenser Stability
Stand holds dispenser up to 50mL,
when screwed on small-size bottles.
Bulk Container Aspiration
Work station facilitates liquid intake
from drum or other remote container
(< 10m distance, < 2m elevation).
Extension Tubing
Autoclavable PTFE delivery Jet-Pen
™
and extension tubing help dispense into vessels
with maximum comfort within a 60cm distance. Fits Calibrex
™
Model 520 dispenser up
to 20mL. Also fits Calibrex Models 525 / 530.
Feed Tubing
Each Calibrex
™
digital
dispenser is supplied with one PTFE feed tubing. Spare feed
tubings are available either cut to the standard size, or uncut by the meter. The latter is
also recommended when aspirating from remote bulk containers.
Ordering Information
Cat. No.
Description
Qty / Pack
W832026
Stand for Calibrex 520 Dispensers*
1
W832028
Stand for remote liquid intake, Calibrex 520*
1
W832030
Stand for remote liquid intake, Calibrex 535, 530*
1
W844136
Stand for Calibrex 525, 530 Dispensers*
1
* Dispenser and feed tube not included, to be ordered separately
Cat. No.
Description
Length Inside Dia.
Extension and Replacement PTFE Tubing
844024 Ext. Tubing for Calibrex 520 Dispensers up to 20mL 600mm 2.2mm
W844149 Ext. Tubing for Calibrex 525/530 Dispensers, 2.5-25mL 600mm 2.2mm
W844150 Ext. Tubing for Calibrex 525/530 Dispensers,
5 - 50mL and 10 - 100mL
600mm 2.2mm
I051154 Replacement Feed Tubing, 520 All Sizes
300mm
5mm
W844124 Replacement Feed Tubing, 525 and 530
350mm
7mm
W844126 Replacement Feed Tubing, 525 and 530
1000mm 7mm
Cat. No.
Shape
Volume
Screw Thread Size Qty / Case
Amber Soda-lime Glass
W832000
Square
100mL
32mm
1
844025
Square
250mL
32mm
1
W844028
Square
500mL
32mm
1
844029
Square
1000mL
45mm
1
844030
Round
2500mL
45mm
1
Amber Soda-lime Glass with Handle
W832004
Round
2500mL
45mm
1
Polyethylene Coated Amber Soda-lime Glass
844027
Square
500mL
32mm
1
W832006
Square
1000mL
45mm
1
W832008
Round
2500mL
45mm
1
Clear Borosilicate Glass with Graduations
W832010
Round
250mL
45mm
1
W832012
Round
500mL
45mm
1
W832014
Round
1000mL
45mm
1
W832016
Round
2000mL
45mm
1
Clear Pyrex
®
Glass with Connection Neck
844026
Round
500mL
32 mm
1
Polyethylene Bottle, HDPE
W832018
Oblong
250mL
25mm
1
W832022
Square
1000mL
32mm
1
W832024
Square
2500mL
45mm
1
Reagent Bottles
Bottle-Top Adapters
The 520 model have a 32mm base thread. They come along
with three Polypropylene bottle neck adapters in 28, 40,
45mm diameters (Model 520). These adapters and others
are available separately.
Cat. No.
Fits Bottle Thread Size (mm)
Qty / Case
Threaded, PP
W830000
22
1
W830002
25
1
844032
28
1
W830006
34
1
W830008
36
1
844035
38
1
W830010
40
1
844038
45
1
Threaded, PTFE
W830012
36
1
W830014
38
1
W830016
40
1
W830018
45
1
Cat. No.
Fits Bottle Taper Size (mm)
Qty / Case
Tapered, PP
W830020
19/26
1
W830024
29/32
1
W830026
45/40
1
Tapered, PTFE
W830029
19/26
1
W830031
24/29
1
W830032
29/32
1
Large selection of glass and Polyethylene reagent bottles,
each supplied with one screw cap. Perfectly adapted
with Calibrex
™
bottle top dispensers. Corresponding neck
adapters supplied with the dispensers.
> 136
Delivery Jets
Cat. No.
Description
Qty / Pack
W844116
Standard Length (120cm) Delivery Jet
for 25mL Calibrex 525, 530 Dispensers
1
W844118
Standard Length (120cm) Delivery Jet
for 50 & 100mL Calibrex 525, 530 Dispensers
1
W844120
Extended Length (150cm) Delivery Jet
for 25mL Calibrex 525, 530 Dispensers
1
W844122
Extended Length (150cm) Delivery Jet
for 50 & 100mL Calibrex 525, 530 Dispensers
1
