WHEATON 2016 Lab Catalog

68 / 196

WHEATON 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
Double Sidearm Celstir ® Spinner Flask
■ For suspension cell culture with
a magnetic stirrer
■ Adjustable paddle impeller and
sterile design as stirrer shaft
does not protrude through cap
■ 1:1 headspace ratio for ideal
gas exchange
■ Bottom dimple to reduce cell
aggregation (dimple on 125mL
and larger flasks)
■ Autoclavable borosilicate glass that conforms to USP Type I and ASTM E 438
Type I, Class A requirements
Cat. No. Volume (mL) Dia. x H (mm) Cap Size, Top Sidearm Size Qty / Case
356873 25 38 x 122 38-430 15-415 1
356875 50 38 x 141 38-430 15-415 1
356876 125 65 x 155 51-400 33-430 1
356879 250 85 x 175 51-400 33-430 1
356882 500 110 x 190 100-400 45mm 1
356884 1000 130 x 250 100-400 45mm 1
356887 3000 178 x 341 100-400 45mm 1
356889 6000 258 x 404 100-400 45mm 1
356890 8000 293 x 445 100-400 45mm 1
Jacketed Double Sidearm Celstir® Spinner Flask
■ For suspension cell culture with a
magnetic stirrer
■ 360° water jacket for precise
temperature control
■ Inlet and outlet hose barb connections
for 0.25” (6.35mm) ID tubing
■ Autoclavable borosilicate glass that
conforms to USP Type I and ASTM
E 438 Type I, Class A requirements
Cat. No. Volume (mL) Dia. x H (mm) Cap Size, Top Sidearm Size Qty / Case
356943 25 54 x 134 38-430 15-415 1
356945 50 54 x 147 38-430 15-415 1
356946 125 80 x 162 51-400 33-430 1
356949 250 100 x 182 51-400 33-430 1
356952 500 130 x 195 100-400 45mm 1
356954 1000 150 x 260 100-400 45mm 1
Magna Flex™ Microcarrier Spinner Flask
■ Designed for microcarrier cultures with a
magnetic stirrer
■ Gentle stirring action provided by a bulb-
shaped glass impeller
■ 1:1 headspace ratio for ideal gas exchange
■ Autoclavable borosilicate glass that
conforms to USP Type I and ASTM E 438
Type I, Class A requirements
Cat. No. Volume (mL) Dia. x H (mm) Cap Size, Top Sidearm Size Qty / Case
356830 125 65 x 155 51-400 33-430 1
356831 250 85 x 175 51-400 33-430 1
356832 500 110 x 190 100-400 45mm 1
356834 1000 130 x 250 100-400 45mm 1
356837 3000 178 x 341 100-400 45mm 1
356839 6000 258 x 404 100-400 45mm 1
Replacement Parts
Stainless Steel Shaft Assembly Kit
Replacement for Double Sidearm Celstir® and Jacketed Double Sidearm Celstir® .
This non-breakable stainless steel shaft, for replacing the glass shaft included with
Celstir ® flasks, may be retrofitted to the existing Celstir® flasks.
Cat. No. For Flask Size (mL) Qty / Case
356874 25 1
356877 50 1
356878 125 1
356880 250 1
356883 500 1
356885 1000 1
356886 3000 1
356888 6000 1
356891 8000 1
Replacement Impeller
Replacement for Double Sidearm Celstir® and Jacketed Double Sidearm Celstir® .
This unit includes a top cap with liners, glass rod, magnet holder, magnet and
stirring paddle.
Cat. No. For Flask Size (mL) Qty / Case
356893 25 1
356895 50 1
356896 125 1
356899 250 1
356902 500 1
356904 1000 1
356907 3000 1
356909 6000 1
356910 8000 1
Replacement Impeller
Replacement for Magna Flex ™ Spinner Flasks. This unit includes a top cap with
liners, glass stirring ball and connecting silicone tubing. This glass impeller assembly
is designed for replacement on all Magna Flex™ style flasks.
Cat. No. For Flask Size (mL) Qty / Case
356841 125 1
356842 250 1
356843 500 1
356844 1000 1
356847 3000 1
356848 6000 1
356849 8000 1
Replacement Flask for Celstir ® and Magna Flex ™
Cat. No. For Flask Size (mL) Qty / Case
Celstir® Only
356913 25 – Celstir® Flask Only 1
356915 50 – Celstir® Flask Only 1
356930 8000 – Celstir® Flask Only 1
Celstir® & Magna-Flex™
356916 125 – Celstir® / Magna Flex™ Flask Only 1
356919 250 – Celstir® / Magna Flex™ Flask Only 1
356922 500 – Celstir® / Magna Flex™ Flask Only 1
356924 1000 – Celstir® / Magna Flex™ Flask Only 1
356927 3000 – Celstir® / Magna Flex™ Flask Only 1
356929 6000 – Celstir® / Magna Flex™ Flask Only 1
Jacketed Celstir® Flask
356963 25 – Jacketed Celstir® Flask Only 1
356965 50 – Jacketed Celstir® Flask Only 1
356966 125 – Jacketed Celstir® Flask Only 1
356969 250 – Jacketed Celstir® Flask Only 1
356972 500 – Jacketed Celstir® Flask Only 1
356974 1000 – Jacketed Celstir® Flask Only 1
> 67 Cell Culture
