Potter-Elvehjem Safe-Grind
®
Tissue Grinder
Replacement Parts
Cat. No.
Description
Qty / Case
358004
2mL Mortar
2
358006
5mL Mortar
2
358008
10mL Mortar
2
358010
15mL Mortar
2
358012
30mL Mortar
2
358014
55mL Mortar
2
358026
2mL Pestle
2
358031
5mL Pestle
2
358036
10mL Pestle
2
358041
15mL Pestle
2
358046
30mL Pestle
2
358051
55mL Pestle
2
Potter-Elvehjem Tissue Grinder with Radial Serrations
■
Serrated PTFE pestle tip design to disperse
homogenate into the mortar cylinder
more efficiently
■
6.3mm diameter stainless steel rod with PTFE
pestle can be used with power homogenization for
soft tissue such as brain or liver
■
Mortar made from WHEATON 33 low extractable borosilicate glass
■
Components are interchangeable eliminating need to keep parts
matched during cleaning
■
Unit can be autoclaved / sterilized to prevent cross contamination
between samples
■
Pestle clearance range: 0.1 – 0.15mm
Cat. No.
Size (mL)
Mortar, OD x Length (mm)
Overall Length (mm) Qty / Case
357969
2
11 x 45
203
2
357974
5
13 x 66
219
2
357979
10
16 x 74
219
2
357984
15
19 x 84
219
2
357989
30
24 x 118
266
2
357994
55
30 x 130
266
2
Potter-Elvehjem Tissue Grinder with Radial Serrations
Replacement Parts
Cat. No.
Description
Qty / Case
358028
2mL Mortar
2
358033
5mL Mortar
2
358038
10mL Mortar
2
358043
15mL Mortar
2
358048
30mL Mortar
2
358053
55mL Mortar
2
357966
2mL Serrated Pestle
2
357971
5mL Serrated Pestle
2
357976
10mL Serrated Pestle
2
357981
15mL Serrated Pestle
2
357986
30mL Serrated Pestle
2
357991
55mL Serrated Pestle
2
Potter-Elvehjem Micro Tissue Grinder
■
Micro size for extremely precise work
when delicate hand operation is required
■
Made from WHEATON 33 low extractable
borosilicate glass
■
Reservoir and pouring lip provide easy decanting
of micro sample
■
Unit can be autoclaved / sterilized to prevent cross
contamination between samples
■
Pestle clearance range: 0.1 – 0.15mm
Cat. No.
Size (mL)
Mortar, OD x Length (mm)
Overall Length (mm) Qty / Case
357844
0.1
4 x 65
110
2
Potter-Elvehjem Micro Tissue Grinder
Replacement Parts
Cat. No.
Description
Qty / Case
357841
0.1mL Pestle
2
357843
0.1mL Mortar
2
Tapered Tissue Grinder
■
Tapered ground glass surface on mortar and pestle
homogenizes connective tissue including heart, muscle,
lung, skin and plant tissue
■
Grinding efficiency is improved and less time is required as
compared to the Tenbroeck and Potter-Elvehjem designs
■
Made from WHEATON 33 low extractable borosilicate glass
■
Components are interchangeably ground eliminating need
to keep parts matched during cleaning
■
Unit can be autoclaved / sterilized to prevent cross
contamination between samples
■
Pestle clearance range: 0.1 – 0.15mm
Cat. No.
Size (mL)
Mortar, OD x Length (mm)
Overall Length (mm) Qty / Case
358103
1
11 x 49
130
1
358107
3
11 x 86
220
1
358111
5
13 x 93
220
1
358115
15
18 x 114
240
1
Tapered Tissue Grinder Replacement Parts
Cat. No.
Description
Qty / Case
358102
1mL Mortar
2
358106
3mL Mortar
2
358110
5mL Mortar
2
358114
15mL Mortar
2
358101
1mL Pestle
2
358105
3mL Pestle
2
358109
5mL Pestle
2
358113
15mL Pestle
2
Tapered Tissue Grinder with Steel Rod
■
Tapered PTFE pestle tip with 6.3mm diameter
stainless steel rod can be used with power
homogenization for soft tissue such as brain
or liver
■
Mortar made from WHEATON 33 low extractable
borosilicate glass
■
Components are interchangeable eliminating need
to keep parts matched during cleaning
■
Unit can be autoclaved / sterilized to prevent cross
contamination between samples
Cat. No.
Size (mL)
Mortar, OD x Length (mm)
Overall Length (mm) Qty / Case
358133
1
11 x 49
130
1
358137
3
11 x 86
220
1
358141
5
13 x 93
220
1
358145
15
18 x 114
240
1
Tapered Tissue Grinder with Steel Rod
Replacement Parts
Cat. No.
Description
Qty / Case
358132
1mL Mortar
2
358136
3mL Mortar
2
358140
5mL Mortar
2
358144
15mL Mortar
2
358131
1mL Pestle
2
358135
3mL Pestle
2
358139
5mL Pestle
2
358143
15mL Pestle
2
