WHEATON
800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
www.wheaton.comWHEATON Micro Kit
®
for Organic and Environmental Chemistry
With Standard Taper 19/22 Clear-Seal
™
Joints
■
Apparatus for a wide range of organic chemistry experiments at a lower price than purchasing the components separately
■
WHEATON standard taper Clear-Seal
™
grease-free joints provide smooth, unground surfaces, which seal without grease and reduce seizing and
contamination from grease
■
Clear-Seal
™
joints can replace ground units in any application and provide other important advantages over ground joints:
• Superior in vacuum and radioactive applications
• Smooth surfaces resist contamination
• Cleaning is simple and thorough
• Interchangeable with ground joints
• All chemical changes and thermometer scales remain visible through the joints
• Clear-Seal
™
joints have never been weakened by grinding and are formed from special wall tubing that is heavier than standard wall for extra strength
• Manufactured from WHEATON 33 low extractable borosilicate glass that conforms to ASTM E 438 Type I, Class A requirements
• Clear-Seal
™
joints are produced to American Standard Taper dimensions and can be used interchangeably with any standard taper ground joints
■
Enjoy Clear-Seal
™
joints exclusively or couple them with ground joints and get maximum results
■
WHEATON Micro Kit
®
catalog number 773900 is packed in a high-density polyethylene case with a foam insert to protect components against breakage
Cat. No.
Description
Qty Included in Kit
Qty / Case
773900
Complete Kit
1
—
Component and Replacement Parts
109933
Claisen Adapter
1
1
123753
Connecting Adapter
1
1
139479
Thermometer Adapter with “O” ring, 13-425 Cap 1
1
168353
Vacuum Distilling Adapter
1
1
327342
West Condenser, 200mm
1
1
385772
Distilling Column, 200mm
1
1
WF034088 Round-Bottom Flask, 25mL
1
1
WF034093 Round-Bottom Flask, 50mL
1
1
W438174 Round-Bottom Flask, 100mL
1
1
438764
Round-Bottom Flask, 250mL
1
1
438782
Round-Bottom Flask, 500mL
1
1
690170
Separatory Funnel with PTFE
Stopcock, 125mL
1
1
923769
PTFE Stopper
1
1
964453
Bleed Tube
1
12
109933
123753
168353
923769
964453
139479
690170
385772
327342
W438174
WF034088
438764
438782
> 75
Chemistry Glassware
WF034093
