WHEATON 2016 Lab Catalog

79 / 196

WHEATON 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
With Stainless Steel Support
■ Designed for filtering viscous or proteinaceous solutions or to
produce ultraclean filtrate
■ Includes a 316 stainless steel support with 120 mesh screen, PTFE
support screen gasket, support base, 300mL graduated funnel,
anodized clamp and a No. 8 silicone stopper
Cat. No. Description Qty / Case
419360 Complete Unit 1
Component Parts
419350 Glass Funnel, 47mm, 300mL 1
419354 Aluminum Clamp, 47mm 1
419364 Stainless Steel Support Screen, 47mm 1
419366 Support Screen Gasket, 47mm 6
419362 Glass Base, 47mm, for Stainless Steel Support 1
419356 Silicone Stopper, No. 8 6
Accessories
419410 Glass Funnel, 47mm, 100mL 1
419415 Glass Funnel, 47mm, 500mL 1
419420 Glass Funnel, 47mm, 1000mL 1
635232 Filter Flask, 1L, Graduated, No. 8 Stopper Joint 1
635233 Filter Flask, 2L, Graduated, No. 8 Stopper Joint 1
635245 Filter Flask, 1L, Safety Coated, No. 8 Stopper Joint 1
■ Recommended for routine filtration of organic solvents,
corrosive liquids and the removal of particulates from
HPLC solvents
■ Ground glass connection eliminates phthalate
contamination that can occur from silicone or neoprene
stoppers
■ Drip tip on the support bases extends below the hose
connection preventing filtrate from entering the vacuum
line
■ Units have a #2 hose connection for 1/4” (6mm) I.D.
flexible tubing
■ Glass components manufactured from WHEATON 33 low
extractable borosilicate glass that conforms to USP Type
I and ASTM E 438 Type I, Class A requirements
47mm Filtration Assembly with Standard Taper 40/35
Joint Connection
With Fritted Glass Support
■ Recommended for general filtration
■ Includes a coarse porosity (40-60μm) fritted glass support base,
graduated funnel, anodized aluminum clamp and 1L filter flask
Cat. No. Description Qty / Case
419380 Complete Assembly with 300mL Funnel, 1L Flask 1
419385-47 Complete Assembly with 500mL Funnel, 2L Flask 1
Component Parts
419350 Glass Funnel, 47mm, 300mL 1
419415 Glass Funnel, 47mm, 500mL 1
419354 Aluminum Clamp, 47mm 1
419382 Fritted Glass Support Base, 47mm, with 40/35 Outer Joint 1
635525 Filter Flask, 1L, with 40/35 Inner Joint 1
635526 Filter Flask, 2L, with 40/35 Inner Joint 1
Accessories
419410 Glass Funnel, 47mm, 100mL 1
419420 Glass Funnel, 47mm, 1000mL 1
635527 Filter Flask, 1L, with 40/35 Inner Joint, Safety Coated 1
With Stainless Steel Support
■ Designed to filter viscous or proteinaceous solutions or produce an
ultra clean filtrate
■ Includes a 316 stainless steel support with 120 mesh screen, PTFE
support screen gasket, glass support base, 300mL graduated funnel,
anodized aluminum clamp and 1L filter flask
Cat. No. Description Qty / Case
419390 Complete Unit 1
Component Parts
419350 Glass Funnel, 47mm, 300mL 1
419354 Aluminum Clamp, 47mm 1
419364 Stainless Steel Support Screen, 47mm 1
419366 Support Screen Gasket, 47mm 6
419392 Glass Base, 47mm, with 40/35 Outer Joint, for Stainless Steel Support 1
635525 Filter Flask, 1L, with 40/35 Inner Joint 1
Accessories
419410 Glass Funnel, 47mm, 100mL 1
419350 Glass Funnel, 47mm, 300mL 1
419415 Glass Funnel, 47mm, 500mL 1
419420 Glass Funnel, 47mm, 1000mL 1
635527 Filter Flask, 1L, with 40/35 Inner Joint, Safety Coated 1
> 78 Chemistry Glassware
