11mm Aluminum Crimp Seals
for 12 x 32mm Vials
MicroLiter understands the autosampler vial and septum’s relationship
with the prepared sample and the analytical instrument. The last thing
anyone wants is a contaminant or crash that is traced back to the
consumable. MicroLiter offers the right products for all instrument
platforms and can work with you to determine the best solution for your
particular sample.
MicroLiter makes a big effort to help you maintain a consistent product
lot to lot, year after year. Our packaging assists you in quick visual
reference for identification of septum specification. The packs also mate
with a handy dispenser for closed container storage after opening.
MicroLiter Defines PTFE / Red Rubber Septa
Can you tell the difference? Your GC can. Use this guide to
maximize the quality of your chromatography!
Red Rubber is the most commonly misused term with regard to septa
manufacturing. Every chromatography consumables supplier sells PTFE
/ Red Rubber. All are low priced. All are sold in high quantities. Almost
all are different formulations. Until recently, MicroLiter sold a variety of
formulations under one product number. Because the instruments have
advanced since the introduction of these products, and the demand for
consistency is on the rise, we thought it might be useful to define the
various forms and change slightly the way we sell it.
Red Rubber originally was a thin layer of FEP and a relatively thick layer
of Natural Rubber. This material was plentiful in the pharmaceutical
industry and its low cost made it the industry standard material for
gas chromatography. Polybutyl Isoprene, manufactured as a synthetic
alternative to Natural Rubber, is also a popular formulation.
Because cost was the primary decision for specifying Red Rubber, Silicone
manufacturers entered the red rubber market with their version of PTFE
/ Red Rubber. A specification of FEP-backed or ETFE-backed Burnt
Red Silicone provided the lower material costs necessary to compete
with the Butyl and rubber materials. Overall, Silicone manufacturers
have brought about a more competitive market, benefiting those who
purchase mainly on price.
The only issue related to these products stems from those customers
who use Butyl or Natural Rubber because Silicone interferes with their
chromatograms. Cost is not the issue with this group of customers.
A Variety of Product Numbers for PTFE / Red
Rubber
To eliminate any confusion MicroLiter now offers, depending on the
product line, a variety of different PTFE / Red Rubber specifications so
that you can consistently order the same material.
You will see these listings in each product line, listed first as PTFE / Red
Rubber, then as the product number series that matches the material
specs. Our customer service representatives can assist you in selecting
the correct formulation. If you desire, we will send you enough samples
so that you can make a quantifiable decision.
Chromatography Vials, Caps & Inserts
11mm Crimp Seals
Approved
Qty /
Cat. No.
for LC / GC
Description
Pack
PTFE / Red Rubber
11-0020A GC Only Aluminum w/ FEP / Natural Rubber
100
11-0020A-B GC Only Aluminum w/ FEP / Natural Rubber - Bulk 2000
11-0020AT GC Only AlumiTin
™
w/ FEP / Natural Rubber
100
11-0020B GC Only Blue Seal w/ FEP / Natural Rubber
100
11-0020BT GC Only Blue AlumiTin w/ FEP / Natural Rubber
100
11-0020G GC Only Green Seal w/ FEP / Natural Rubber
100
11-0020GT GC Only Green AlumiTin w/ FEP / Natural Rubber
100
11-0020R GC Only Red Seal w/ FEP / Natural Rubber
100
11-0020RT GC Only Red AlumiTin w/ FEP / Natural Rubber
100
11-0020Y
GC Only Yellow Seal w/ FEP / Natural Rubber
100
11-0020YT GC Only Yellow AlumiTin w/ FEP / Natural Rubber
100
11-0021A GC Only Aluminum w/ FEP / Butyl
100
11-0021A-B GC Only Aluminum w/ FEP / Butyl - Bulk
2000
11-0021AT GC Only AlumiTin w/ FEP / Butyl
100
11-0021B GC Only Blue Seal w/ FEP / Butyl
100
11-0021BT GC Only Blue AlumiTin w/ FEP / Butyl
100
11-0021G GC Only Green Seal w/ FEP / Butyl
100
11-0021GT GC Only Green AlumiTin w/ FEP / Butyl
100
11-0021R GC Only Red Seal w/ FEP / Butyl
100
11-0021RT GC Only Red AlumiTin w/ FEP / Butyl
100
11-0021Y
GC Only Yellow Seal w/ FEP / Butyl
100
11-0021YT GC Only Yellow AlumiTin w/ FEP / Butyl
100
11-0022A GC Only Aluminum w/ ETFE / Burnt Red Silicone
100
11-0022A-B GC Only
Aluminum w/ ETFE / Burnt Red Silicone - Bulk
2000
11-0022AT GC Only AlumiTin w/ ETFE / Burnt Red Silicone
100
11-0022B GC Only Blue Seal w/ ETFE / Burnt Red Silicone
100
11-0022BT GC Only Blue AlumiTin w/ ETFE / Burnt Red Silicone 100
11-0022G GC Only Green Seal w/ ETFE / Burnt Red Silicone 100
11-0022GT GC Only Green AlumiTin w/ ETFE / Burnt Red Silicone 100
11-0022R GC Only Red Seal w/ ETFE / Burnt Red Silicone
100
11-0022RT GC Only Red AlumiTin w/ ETFE / Burnt Red Silicone 100
11-0022Y
GC Only Yellow Seal w/ ETFE / Burnt Red Silicone 100
11-0022YT GC Only Yellow AlumiTin w/ ETFE / Burnt Red Silicone 100
PTFE / Silicone / PTFE and PTFE / Silicone
11-0030A GC Only Aluminum w/ PTFE / Silicone, 0.040”
100
11-0030A-B GC Only Aluminum w/ PTFE / Silicone, 0.040” - Bulk 2000
11-0030AT GC Only AlumiTin w/ PTFE / Silicone, 0.040”
100
11-0030M GC Only Magnetic Seal w/ PTFE / Silicone, 0.040”
100
11-0040A
Yes
Aluminum w/ PTFE / Silicone / PTFE
100
11-0040A-B Yes
Aluminum w/ PTFE / Silicone / PTFE - Bulk 2000
11-0040AT
Yes
AlumiTin w/ PTFE / Silicone / PTFE
100
11-0040M Yes
Magnetic Seal w/ PTFE / Silicone / PTFE
100
11-0060A GC Only Aluminum w/ PTFE / Silicone, 0.060”
100
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
