MicroLiter Catalog

26 / 60

> 24 Chromatography Vials, Caps & Inserts
Snap Cap Vials, 2.0mL, 12 x 32mm
Color-Coded Caps Now Available
Snap Caps and SnapTins™ are now available in six colors. Snap Cap vials
are an excellent choice if convenience and ease-of-use are important.
Snap Cap closures have proven themselves to be an excellent alternative
in HPLC because less volatile samples or high throughput labs benefit
from the time saved over crimp top and screw thread vials.
The septa material used in these caps are the right products for the
instruments you use. Purchase the components separately or as a
component kit with 100 vials and 100 Snap Cap closures with septa.
SnapTin ™ Caps for CTC Analytics Combi PAL ®
MicroLiter leads the way for complete
consumables solutions for CTC Analytics
Combi PAL® Sample Handlers. If you are
considering bar code applications or
special handling where you must move the
vial from one position on the PAL® System
to another, use our snap cap with the metal
ring installed.
If your sample is heavy MicroLiter offers
a needle guide that intensifies magnetic
force. See SnapTin™ listings.
Also available in 9mm screw
threads and 11 & 20mm crimp
Product Specifications
Vials
■ Closure Requirement............11mm Snap Caps or 11mm Crimp Top Seal
■ Glass, Clear .............................Class 10,000 Clean, Type I, Borosilicate
■ Glass, Amber ..........................Class 10,000 Clean, Type I, Borosilicate
■ Plastic, All.................................100% Virgin Medical Grade Polypropylene
■ Silanization Type.....................Vapor Phase Method
Inserts
■ Glass, Clear...............................Type I, Borosilicate
■ Plastic, All.................................100% Virgin Medical Grade Polypropylene
■ Attached Springs....................Polyethylene
■ Silanization Type.....................Vapor Phase Method
Septa
■ PTFE Disk..................................0.010” PTFE
■ FEP / Butyl................................0.002” Clear FEP / 0.035” Burnt Red Butyl
■ PTFE / Silicone........................0.005” Red PTFE / 0.035” White Silicone
■ PTFE / Silicone, Pre-Cut.......0.005” Blue PTFE / 0.035” White Silicone
■ PTFE / Silicone, Starburst, Pre-Cut
0.005” Yellow PTFE / 0.035” White Silicone
■ PTFE / Silicone / PTFE..........0.005” Red PTFE / 0.030” White Silicone /
0.005” Red PTFE
Dispensersareshippedwithbothsmall and large tubeadapters.Use
the large volume adapter to keep your vials clean after opening the
pack. All Polypropylene vials are shipped in tubes. Tube packaging
is color-coded for easy identification of septa.
MicroLiter Dispenser
Cat. No. Qty / Kit
00-DISP Sold Individually w/ Adapter
MicroLiter 888.232.7840 (TF) | 770.932.6565 (INT’L) | |
