WHEATON R2P 2.0 Roller Apparatus

5 / 6

R2P 2.0
Advanced touch screen with
remote communications and alarms
STANDARD
Digital display
Top Mounted
Ideal design for rigorous cleaning
and ceiling mounted connections
Bottom Mounted
Ideal design for easy access and floor
mounted connections
Production (6”/152mm)
Smaller spacing between decks to allow for
more bottles per area
Modular (7.125”/181mm)
Larger spacing between decks to allow easier
removal and replacement of bottles
Fixed
Fixed size with a single piece uprights used for production
and lighter weight due to less hardware
Removale
Removable decks for flexible design
01-11: Number of Decks
Modular spaced units have a maximum of 9 decks, production spaced
units have a maximum of 11 decks
5
Five placement areas per deck allows for use with an upright incubator
8
Eight placement areas is used for large scale production type installions
0
No options included
1
Options Included
Standard Roller options include belt break alarm and battery backup
R2P 2.0 options include temperature monitoring and alarms (2 probes) and battery backup (Belt break alarm included in base o’ering)
Control System
Decks
Capacity
Options
Control System Type
Control System Location
Spacing Plug Style
Deck Type
Postions per Deck
No. of Decks
Options
R - R2P 2.0
S - Standard
T - Top Mounted
B - Bottom Mounted
A - North America - 120 VAC
B - Japan - 100 VAC
C - Continental Europe - 230 VAC
D - United Kingdom - 230 VAC
F - Australia/China - 240 VAC
G - Italy/Chile - 230 VAC
J - India - 230 VAC
P - Production
M - Modular
F - Fixed
R - Removable
5
8
01-11
0
1
Example: W R T P F 5 11 1 - A
Configuration Matrix for Easy Ordering
Ordering Information
DWK Life Sciences specializes in standard and customized roller apparatus units. The part numbering system below allows for the configuration of a
standard system. The main components that make up a unit include the control system, the size and type of roller bottle decks and system options. There
is also a table listing the most commonly manufactured roller apparatus. If you have any questions about custom bottle sizes, rotation speeds or standard
systems, please contact your DWK Life Sciences Representative.
Roller Belts
Mount for
Belt Guard
Main Belt Drive
Back of Unit
