Belt Break Alarm
The
Belt Break Alarm employs two magnetic sensors
to ensure that all
main pulleys are rotating on the unit. This is included on all R2P 2.0 Roller
Apparatus.
Battery Backup
The
Battery Backup protects cells during transport,
processing and
power outages. The unit automatically and seamlessly switches over to
battery power to provide rotation for 8 – 18 hours. Bottom mounted control
systems house larger, longer lasting batteries.
Temperature Monitoring/Alarm Option
This option
includes two precision temperature probes
for real time
temperature monitoring and deviation alarms. The temperature is
displayed in the temperature calibration screen or on the screen saver for
quick confirmation of optimal operating conditions.
Deck Kit
Cat. No.
Description
W348890V2
WHEATON Standard Roller Top Drive System Options with
Belt Break Alarm and Battery Backup
W348891V2
WHEATON Standard Roller Bottom Drive System Options
with Belt Break Alarm and Battery Backup
W348892V2
R2P 2.0 Roller Top Drive System Options with Battery
Backup and Temperature Sensors
(Belt Break Alarm is already included with unit)
W348893V2
R2P 2.0 Roller Bottom Drive System Options with Battery
Backup and Temperature Sensors
(Belt Break Alarm is already included with unit)
W348887Deck Installation Kit for Modular (7.125”) Spaced System
(Units have a maximum capacity of 9 decks)
W348889
Deck Installation Kit for Production (6”) Spaced System
(Units have a maximum capacity of 11 decks)
Product Specifications
Standard Roller
Roller Options Information
■
Smooth
ramping digitally controlled
rotation accurate to 0.01 RPM
■
Maintenance free precision
brushless motor
■
Bright digital display
for easy operation
■
Multiple decking and capacity configurations
available for process
flexibility
Capacity:.........................................................................................................5-88 Positions
Bottle Speed (110mm Diameter Bottle, other speeds available):....0.25-8.1 RPM
Bottle Diameter:...............................................................................................108-121mm
Bottle Length:................................................................................................ Up to 550mm
Accuracy:................................................................................................................ 0.01 RPM
Drive:..................................................................................................................... Belt Driven
Motor Type:......................................................................................................Brushless DC
Rotation Direction:..................................................Clockwise and Counter-Clockwise
Options:..............................................................Belt Break Alarm and Battery Backup
Remote Communication:........................................................Dry Contact Relay Alarm
Humidity:......................................................................................................80% up to 31°C
Operating Temperature:.................................................................................... 10 to 40°C
Electrical:............................................................................100-240 VAC, 50/60 Hz, 35W
Specifications
WHEATON
®
Standard Roller Apparatus
WBRO_049b 09/2017
