WHEATON 2015 Lab Catalog

63 / 196

WHEATON 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
Staining Jar, 8-10 Slide Unit
■ The jar holds 8 single 3” x 1” (75mm x 25mm) slides
vertically or 16 slides back-to-back
■ This jar’s wide top is designed for convenience in
transferring slides, making it especially suitable for
staining slides that are inscribed on one end
■ Manufactured from soda-lime glass
■ Approximate inside bottom dimensions:
47mm L x 26mm W x 85mm D
Cat. No. Description Qty / Case
900620 Staining Jar with Cover 6
Slide Grip
■ Polypropylene grip allows for easy and
safe transfer of five slides to other
containers for staining
■ Fits into WHEATON Coplin
staining jars (900570, 900470, 276840)
Cat. No. Description Qty / Case
900575 Slide Grip 2
Boerner Micro Test Slide
■ Ideal for Boerner-Jones-Lukens
microflocculation test
■ This slide is used for procedures
involving 0.01 to 0.15mL of fluid
■ The slide has 10 cells in two rows of five each
■ Each cell is 2.5mm deep and is designed to
produce flattened drops of uniform depth
■ Manufactured from soda-lime glass
Cat. No. Description Dimensions L x W (mm) Qty / Case
798550 Boerner Micro Test Slide 109 x 58 12
Mounting Media / Balsam Bottle
■ This bottle, manufactured from soda-lime glass,
is ideal for applying mounting media
■ It comes with a glass applicator rod and a glass
cap, which is ground to the shoulder of the
bottle to form a seal
Cat. No. Size (mL) Dia. x H (mm) Qty / Case
208890 100 75 x 100 6
Replacement Parts
Cat. No. Description Dia. x H (mm) Qty / Case
W208892 Glass Applicator — 2
Alcohol Burner
■ Glass cap is used to reduce evaporation of
alcohol when not in use
■ This burner, manufactured from soda-lime glass,
is designed for use with isopropyl or denatured
ethyl alcohol
■ Its low-heat flame is well suited for microscopy
purposes
■ The unit is supplied with a ground glass cap
■ The reservoir holds 100mL of alcohol
Cat. No. Description Dia. x H (mm) Qty / Case
237070 Alcohol Burner 75 x 100 6
Replacement Parts
237071 Wick, 0.25” Dia x 6” L — 25
237072 Cork Stopper Assembly — 10
Coplin Staining Jar, 5-10 Slide Unit
■ This unit holds ten 3” x 1” (75mm x 25mm)
slides, back-to-back that extend above the
opening so you can manipulate them without
using forceps
■ Polypropylene screw cap
■ The screw cap is made of linerless
white polypropylene to reduce solvent
evaporation and spills during storage
■ Cap is not intended for use with slides in jar
■ The unit has a rectangular base and
holds approximately 55mL
■ Manufactured from soda-lime glass
■ Approximate inside bottom dimensions: 26mm L x 26mm W x 70mm D
Cat. No. Description Qty / Case
900520 Coplin Jar with PP Screw Cap 6
900522 Replacement Cap, 58-400 6
Coplin Staining Jar, 5-10 Slide Unit,
with Screw Cap
■ It holds five single 3” x 1” (75mm x 25mm) slides
vertically, or 10 slides back-to-back
■ This unit is used for staining slides, or as a
developing chamber for thin-layer chromatography
■ The screw cap is made of linerless white
polypropylene to reduce solvent evaporation
■ The unit has a rectangular base and holds
approximately 60mL
■ Manufactured from soda-lime glass
■ Approximate inside bottom dimensions:
26mm L x 26mm W x 90mm D
Cat. No. Description Qty / Case
900570 Complete 6
900522 Replacement Cap, 58-400 6
Coplin Staining Jar, 5-10 Slide Unit
■ It holds five single 3” x 1” (75mm x 25mm) slides
vertically, or 10 slides back to back, and holds
approximately 65mL
■ This popular staining jar has heavy glass walls and
a broad base for increased stability
■ Manufactured from soda-lime glass
■ Approximate inside bottom dimensions:
28mm L x 26mm W x 92mm D
Cat. No. Description Qty / Case
900470 Coplin Jar with Glass Cover 6
Coplin Staining Jar, 5-10 Slide Unit
■ The chamber is designed with an extra tall lid to accept
5 single 25mm x 75mm and 25mm x 100mm slides or
10 slides back-to-back
■ Extra tall lid accommodates 100mm slides
■ Manufactured from soda-lime glass
■ Approximate inside bottom dimensions:
28mm L x 26mm W x 92mm D
Cat. No. Description Qty / Case
276840 Staining Jar with Lid 6
