Refer to page 189-190 for plug styles.
> 58 Cell Culture
Standard Incubator CO2 Incubator
■ Compatible with:
• Production-spaced R2P 2.0 and Standard rollers with up to 11 decks
• Modular-spaced R2P 2.0 and Standard rollers with up to 9 decks
■ User configurable shelving system and roller apparatus guide tracks (shelves
sold separately)
■ Power outlets for magnetic stirrers or orbital shakers
■ Designed for temperature uniformity
■ Viewing window with an option for dual windows
Cat. No. Plug Style Voltage Qty
753680 North America 120 VAC 1
W753680-B Japan 100 VAC 1
W753684-C-E Continental Europe 230 VAC 1
W753684-D-E United Kingdom 230 VAC 1
W753684-F-E Australia / China 230 VAC 1
W753684-G-E Italy / Chile 230 VAC 1
W753684-J-E India 230 VAC 1
Capacity:........................................................................................40 Cubic ft
Interior Dimensions: W x D X H
.................................................................... 35 x 26 x 76” (89 x 66 x 193cm)
Exterior Dimensions: W x D X H
.................................................................. 41 x 34 x 87” (104 x 86 x 221cm)
Control:....................................................... Microprocessor Controlled ±0.1°C
Temperature Range:...............................................8°C Above Ambient to 70°C
Temperature Uniformity:
..............................................................Forced Air Circulation ±0.5ºC at 37ºC
Electrical:...................................................... 100-240 VAC, 50/60 Hz, 12A-8A
Shelving:.....................................................................................20 Maximum
Interior Electrical Outlet:................................................................................4
Net Weight:............................................................................... 730lb (331kg)
Shipping Weight:........................................................................ 850lb (386kg)
Specifications
■ Compatible with:
• Production-spaced R2P 2.0 and Standard rollers with up to 11 decks
• Modular-spaced R2P 2.0 and Standard rollers with up to 9 decks
■ Infared sensor technology to maintain 0 to 20% CO2 concentration
■ Stainless steel interior
■ User configurable shelving system and roller apparatus guide tracks (shelves
sold separately)
■ Power outlets for magnetic stirrers or orbital shakers
■ Designed for temperature uniformity
■ Viewing window with an option for dual windows)
Cat. No. Plug Style Voltage Qty
WI057607 North America 120 VAC 1
WI057607-C-E Continental Europe 230 VAC 1
WI057607-D-E United Kingdom 230 VAC 1
WI057607-F-E Australia / China 230 VAC 1
WI057607-J-E India 230 VAC 1
Capacity:...................................................................................... 40 Cubic ft
Interior Dimensions: W x D X H
................................................................35 x 26 x 76.5” (89 x 66 x 194cm)
Exterior Dimensions: W x D X H
...........................................................41 x 34 x 89.1” (104 x 86 x 226.3cm)
Control:......................................................Microprocessor Controlled ±0.1°C
Temperature Range:............................................. 8°C Above Ambient to 70°C
Temperature Uniformity:
............................................................ Forced Air Circulation ±0.5ºC at 37ºC
Electrical:...................................................100-240 VAC, 50/60 Hz, 15A-10A
CO2 Range:........................................................................................ 0-20%
CO2 Sensor:...............................................................................................IR
CO2 Rate:........................................................................... <5min (Recovery)
CO2 Connection:........................................................¼” (6.35mm) Hose Barb
CO2 Inlet pressure:................................................ 5-40 psi (0.345-2.76 bars)
Jacket Type:............................................................................................. Air
Shelving:................................................................................... 30 Maximum
Interior Electrical Outlet:.............................................................................. 4
Net Weight:..............................................................................730lb (331kg)
Shipping Weight:.......................................................................850lb (386kg)
Specifications
Incubator Shelves (Not Supplied with Incubators)
Cat. No. Description Qty
753685 Painted Shelf for Standard 1
WI056028 Stainless Steel Shelf for CO2 1
Refer to page 189-209 for plug styles.
