61 / 196
WHEATON
800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
www.wheaton.com> 60
Cell Culture
Bench-Top Systems – Small Bottle
Additional Deck Kit
Cat. No.
Plug Style
Voltage
Qty / Case
W348924-A
North America
120 VAC
1
W348924-B
Japan
100 VAC
1
W348924-C
Continental Europe
230 VAC
1
W348924-D
United Kingdom
230 VAC
1
W348924-F
Australia / China
240 VAC
1
W348924-G
Italy / Chile
230 VAC
1
W348924-J
India
230 VAC
1
Cat. No.
Description
Qty / Case
W348930-CH
Deck Kit for Small Bottle Bench-Top Roller Rack
1
■
Allows for use with glass or plastic roller bottles
■
For cell cultivation research and
pilot applications
■
Accommodates two bottles 75 to 121mm in
diameter and 290 mm long
■
Deck kits available to double or
triple capacity
Capacity: ......................................................................................2-6 Positions
Bottle Speed: ...........................................0.1-3.8 RPM (110mm diameter bottle)
Bottle Diameter:.............................................................................108-121mm
Bottle Length: .............................................................................. Up to 290mm
Weight:..............................................................................................18lb (8kg)
Dimensions: W x D X H ..................... 12.25 x 12.75 x 7.125” (32 x 32.5 x 18cm)
Humidity:................................................................................. 80% up to 31°C
Operating Temperature: ....................................................................10 to 40°C
Electrical:............................................................. 100-240 VAC, 50/60 Hz, 14W
Specifications
CART
2
Screen
Computer Requirements
■
IBM Pentium PC or compatible
■
32 MB of RAM, minimum
■
Microsoft
®
Windows
®
2000, XP
■
One free serial port
■
10 MB of free hard drive space, minimum
CART
2
and View Log Software
with the Network Interface
Network Interface is a single-line network adapter for up to
255 R2P units.
Cat. No.
Plug Style
Voltage
Qty / Case
W348902-A
North America
120 VAC
1
W348902-B
Japan
100 VAC
1
W348902-C
Continental Europe
230 VAC
1
W348902-D
United Kingdom
230 VAC
1
W348902-F
Australia / China
240 VAC
1
W348902-G
Italy / Chile
230 VAC
1
W348902-J
India
230 VAC
1
CART
2
Control Monitor and Recording Software
Software
The WHEATON CART
2
System precisely controls rotating speeds of up to 255 separate
roller units. Each unit is monitored for rotation, speed deviation and communication.
This system provides the perfect solution for GMP or FDA requirements.
■
Remotely monitors and controls up to 255 R2P
™
rollers
■
Records all settings, changes, alarms and communication loss
■
Password-protected user levels maintain security
■
Can be easily added to R2P
™
at any time
■
Conforms to UL, CSA and CE Laboratory Standards
Refer to page 189-190 for plug styles.
Refer to page 189-190 for plug styles.
