Safety Coated Jar
Safety Coated Lab 45™ Media / Reagent Bottle
■ Plastisol coating for safety
■ Made from clear borosilicate glass
■ 45mm white polypropylene screw cap attached
■ Pour ring eliminates drips
■ Autoclavable
■ Color coded caps available separately
Cat. No. Size (mL) Approx Dia. x H (mm) Cap Size (mm) Qty / Case
W219937 250 70 x 144 45 12
219939 500 86 x 186 45 12
219940 1000 101 x 233 45 12
Cat. No. Description Size (mm) Qty / Case
240726 White PP, w/ Wedge-Shaped Inner Sealing Ring 45 12
240726-03 Red PP, w/ Wedge-Shaped Inner Sealing Ring 45 12
240726-04 Blue PP, w/ Wedge-Shaped Inner Sealing Ring 45 12
W240726-05 Pink PP, w/ Wedge-Shaped Inner Sealing Ring 45 12
Safety Coated Media / Lab Bottle
Safety Coated Reagent Bottle
Safety Coated Solution Bottle
Screw Caps, Black Phenolic
■ Plastisol coating for safety
■ Made from clear soda-lime glass that conforms to
USP Type III requirements
■ Wide mouth for use with solid samples
■ Available with or without caps
Cat. No. Approx Size (oz) Cap On* Cap Off* Cap Size Cap Material/Liner Qty / Case
216637 8 75 x 92 75 x 90 70-400 Without Cap (Autoclavable) 12
216627 8 75 x 92 75 x 90 70-400 With Poly-Vinyl Lined Black Phenolic Cap 12
216639 16 78 x 147 78 x 145 70-400 Without Cap (Autoclavable) 12
216629 16 78 x 147 78 x 145 70-400 With Poly-Vinyl Lined Black Phenolic Cap 12
W216641 32 95 x 182 95 x 180 89-400 Without Cap (Autoclavable) 12
W216631 32 95 x 182 95 x 180 89-400 With Poly-Vinyl Lined Black Phenolic Cap 12
* Dia. x H (mm)
■ Plastisol coating for safety
■ USP Type I clear borosilicate glass
■ Provided with graduations and writing patch
■ 33-430 screw cap can be purchased separately
■ Autoclavable
Cat. No. Size (mL) Approx Dia. x H (mm) Cap Size Qty / Case
219455 125 55 x 119 33-430 48
219457 250 67 x 148 33-430 48
Cat. No. Cap Size Liner Qty / Case
240280 33-430 14B White Rubber Liner 200
240080 33-430 Polyethylene (LDPE) Liner* 200
240480 33-430 PTFE Faced (14B) Styrene-Butadiene 100
* Not autoclavable
■ Plastisol coating for safety
■ Clear borosilicate glass with writing patch
■ 33-430 screw cap attached
■ Polypropylene cap with PTFE liner
■ 125 and 250mL size
■ Autoclavable
Cat. No. Size (mL) Approx Dia. x H (mm) Cap Size Qty / Case
221014 125 58 x 122 33-430 6
221017 250 69 x 151 33-430 6
■ Plastisol coating for safety
■ Made from low extractable borosilicate glass
■ Serum finish takes rubber stopper closure
Cat. No. Size Approx Dia. x H (mm) Stopper Size Qty / Case
221029 5 gallon 294 x 502 12 1
