WHEATON 2016 Lab Catalog

26 / 196

WHEATON 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
■ Polypropylene screw caps in 5 colors
■ Use with 224100-203 or W224100-185 thin flange stopper
■ Autoclavable
Screw Caps for Screw Neck Diagnostic Bottles
Serum Bottle
Screw Neck Diagnostic Bottle
I-Loc™ Closure
Stopper, Thin Flange
■ For use with Screw Neck Diagnostic Bottles
■ Advantages of an aluminum seal with the
convenience of a screw cap
■ Polypropylene screw cap with gray
bromobutyl / 50 stopper
■ Autoclavable
Cat. No. Color Cap Size Qty / Case
240676-01 Black 20-400 100
240676-02 White 20-400 100
240676-03 Red 20-400 100
240676-04 Blue 20-400 100
240676-05 Yellow 20-400 100
■ Use with screw caps for Screw Neck
Diagnostic Bottles
■ Autoclavable
Cat. No. Stopper Size Qty / Case
224100-203 20mm 3-Leg Lyophilization Gray Chlorbutyl / 55 300
W224100-185 20mm Thin Flange Snap-On Gray Chlorbutyl / 50 1000
■ Alternative to serum bottles and vials
■ Can be used for lyophilization
■ Fits with I-Loc ™ closure
or screw cap with thin flange stopper
■ Superior chemical resistance
■ Manufactured from WHEATON 400 borosilicate glass
that conforms to USP Type I requirements
■ Autoclavable
Cat No. Color Capacity (mL) Dia. x H (mm) Cap Size Qty / Case
219371 Amber 10 25 x 61 20-400 480
■ Ideal for long and short term sample storage, lyophilization and
vaccine / injectable drug containers
■ Fits most lyophilization applications
■ Borosilicate glass conforms to USP Type I requirements
■ Clear bottles manufactured from WHEATON 400 borosilicate molded glass that
conforms to USP Type I requirements
■ Amber bottles manufactured from WHEATON 500 borosilicate glass that
conforms to USP Type I requirements
■ Shrink-wrapped partitioned modules reduce breakage
Cat. No. Color Size (mL) Mouth ID x OD (mm) Dia. x H (mm) Fits Rack Qty / Case
W223712 Clear 2 7 x 13 15.6 x 36 868810 288
223738 Clear 5 13 x 20 23 x 47 868805 288
223760 Amber 5 13 x 20 23 x 47 868805 288
223739 Clear 10 13 x 20 25 x 54 868806 288
223761 Amber 10 13 x 20 25 x 54 868806 288
223742 Clear 20 13 x 20 32 x 58 — 288
223762 Amber 20 13 x 20 32 x 58 — 288
223743 Clear 30 13 x 20 37 x 63 — 288
223763 Amber 30 13 x 20 37 x 63 — 288
223745 Clear 50 13 x 20 43 x 73 — 288
223764 Amber 50 13 x 20 43 x 73 — 288
223746 Clear 60 13 x 20 41 x 91 — 144
223747 Clear 100 13 x 20 52 x 95 — 144
223766 Amber 100 13 x 20 52 x 95 — 144
223748 Clear 125 13 x 20 54 x 107 — 144
*Note: Select aluminum seal and stopper size by using the mouth OD dimension of the bottle or vial
> 25 Glass Bottles
Serum Bottle, PVC Dropper Tip
■ Create a dropper bottle using a serum bottle with
20mm OD finish
■ Dropper tip is made from PVC with PE cap
■ Dispenses 40μL drop using distilled water
■ Economical way to convert a glass serum bottle to a
dropping bottle
Cat. No. Description Dia. x H (mm) Qty / Case
224080 PVC Dropper Tip 23 x 44 100
Cat. No. Cap Size Cap Style Color Autoclavable Qty / Case
240706-01 20-400 Solid Top Black Yes 300
240706-02 20-400 Solid Top White Yes 300
240706-04 20-400 Solid Top Blue Yes 300
240706-05 20-400 Solid Top Yellow Yes 300
240716-01 20-400 Open-Top Black Yes 300
240716-02 20-400 Open-Top White Yes 300
240716-03 20-400 Open-Top Red Yes 300
240716-04 20-400 Open-Top Blue Yes 300
240716-05 20-400 Open-Top Yellow Yes 300
