Serum Tubing Vial
Serum Bottle, Graduated
■ Raised graduations indicate approximate
capacities in milliliters
■ Accepts standard stoppers and seals
■ Manufactured from WHEATON 400 borosilicate
glass that conforms to USP Type I requirements
Cat. No. Size (mL) Mouth ID x OD (mm) Dia. x H (mm) Qty / Case
223950 250 15 x 30 60 x 158 35
223952 500 15 x 30 75 x 190 24
■ Clear vials are manufactured from low extractable borosilicate glass that
conforms to USP Type I and ASTM E 438 Type I, Class A requirements
■ The amber vials are manufactured from low extractable borosilicate glass that
conforms to USP Type I requirements
■ Special design adds strength for freeze-drying applications
■ Shrink-wrapped modules reduce particulate contamination
Cat. No. Color Size (mL) Mouth ID x OD (mm) Dia. x H (mm) Fits Rack Qty / Case
223683 Clear 2 7 x 13 15 x 32 868804 144
223693 Amber 2 7 x 13 15 x 32 868804 144
223684 Clear 3 7 x 13 17 x 38 868810 144
223685 Clear 5 13 x 20 22 x 40 868805 144
223695 Amber 5 13 x 20 22 x 40 868805 144
223686 Clear 10 13 x 20 24 x 50 — 144
223696 Amber 10 13 x 20 24 x 50 — 144
223687 Clear 20 13 x 20 30.5 x 58 — 120
> 26 Glass Bottles
Uni-Dose ® Bottle & Vial
Snap Cap Sample Bottle
■ Pre-attached low density polyethylene snap caps
■ Ideal for collecting, storing, and exhibiting
sample in the lab or field
■ Packaged in corrugated trays
with partitions
■ Manufactured from WHEATON 800
soda-lime clear glass that conforms to
USP Type III requirements
Cat. No. Size (mL) Dia. x H (mm) Cap Size (mm) Qty / Case
225532 4 23 x 27 22 144
225534 8 22 x 39 22 144
225535 12 22 x 51 22 144
225536 16 30 x 40 30 144
225538 24 30 x 52 30 144
225543 30 37 x 50 34 72
225544 60 45 x 60 45 72
225546 120 50 x 95 45 72
Replacement Snap Caps
Cat. No. Cap Size (mm) Qty / Case
242612 22 200
242615 30 200
242616 34 200
242619 45 200
■ Available in amber glass or amber PET (Polyethylene Terephthalate)
■ Mouth OD 28.5mm
■ Use with WHEATON tamper evident safety cap
■ Large labeling surface for easy product identification
■ Manufactured from WHEATON 900 soda-lime amber glass that conforms
to USP Type III requirements
■ Safer alternative to glass and cost less to ship
■ Use the 224316 Crimper to secure the tamper-evident safety caps
(Cat. No. W224198 or W224199) to the bottle or vial
Cat. No. Size (mL) Dia. x H (mm) Trays/Case Qty / Case
Amber Glass Bottle
226732 15 32 x 42 5 500
226733 30 36 x 58 5 500
Amber PET Vial
226772 15 32 x 42 — 450
226773 30 34 x 55 — 300
Tamper Evident Safety Cap
■ For use with Uni-Dose® Bottles and Vials
■ Caps have Pulp / PVDC / PE Liner
Cat. No. Description For Mouth OD (mm) Qty / Case
W224198 Cap for Uni-Dose ® Bottle and Vial 28.5 2500
W224199 Cap with “For Oral Use” Imprint 28.5 5000
224316 Crimper 28.5 1
