WHEATON Standard Roller WHEATON R2P ™ 2.0 Roller Apparatus
■ Smooth ramping digitally controlled rotation accurate to 0.1 RPM
■ Maintenance free precision brushless motor
■ Bright LCD display for easy operation
■ Multiple decking and capacity configurations available for
process flexibility
■ Robust touch screen interface that is easy to view from a distance
■ Readily recognized icons for intuitive navigation
■ Digitally controlled maintenance free motor accurate to 0.01 RPM
■ Capable of remote interface and monitoring through SCADA systems
■ Multiple decking and capacity configurations available for
process flexibility
> 55 Cell Culture
Deck Kit
Capacity:..................................................................................... 5-88 Positions
Bottle Speed (110mm Diameter Bottle, other speeds available):...... 0.25-8.1 RPM
Bottle Diameter:..............................................................................108-121mm
Bottle Length:............................................................................... Up to 550mm
Accuracy:.............................................................................................0.1 RPM
Drive:................................................................................................Belt Driven
Motor Type:...................................................................................Brushless DC
Rotation Direction:........................................... Clockwise and Counter-Clockwise
Options:........................................................ Rotation Alarm and Battery Backup
Remote Communication:......................................................... Dry Contact Relay
Humidity:................................................................................. 80% up to 31°C
Operating Temperature:.....................................................................10 to 40°C
Electrical:............................................................. 100-240 VAC, 50/60 Hz, 35W
Specifications
Capacity:..................................................................................... 5-88 Positions
Bottle Speed (110mm Diameter Bottle, other speeds available):...... 0.25-8.1 RPM
Accuracy:...........................................................................................0.01 RPM
Drive:................................................................................................Belt Driven
Motor Type:...................................................................................Brushless DC
Rotation Direction:..............................Clockwise, Counter-Clockwise and Rocking
Rotation Alarm:..................................................................................... Included
Options:...........................................Temperature Monitoring and Battery Backup
Remote Communication:..............................................................................Yes,
...................... Modbus® Protocol and WHEATON Protocol via Ethernet and RS422
Humidity:................................................................................. 80% up to 31°C
Operating Temperature:.....................................................................10 to 40°C
Electrical:............................................................. 100-240 VAC, 50/60 Hz, 35W
Specifications
NEW touch screen functionality
Main Screen
Bottle Speed
Factory Setup
Profile
Temperature Alarm
Roller Options Information
Rotation Alarm (Included with R2P 2.0) - The rotation alarm employs two magnetic
sensors to ensure that all main pulleys are rotating on the unit. This is included on
all R2P 2.0 Roller Apparatus.
Battery Backup – The battery backup protects cells during transport, processing and
power outages. The unit automatically and seamlessly switches over to battery power
to provide rotation for 12 – 24 hours. Bottom mounted control systems house larger,
longer lasting batteries.
Temperature Monitoring / Alarm Option (R2P 2.0 Only) – This option includes
two precision temperature probes for real time temperature monitoring and deviation
alarms. The temperature is displayed on the touch screen, screen saver for quick
confirmation of optimal operating conditions.
WHEATON Field Installation Options Packages
Cat. No. System
W348890V2 Wheaton Standard Roller Top Drive System Options with Rotation
Alarm and Battery Backup
W348891V2 Wheaton Standard Roller Bottom Drive System Options with Rotation
Alarm and Battery Backup
W348892V2 R2P 2.0 Roller Top Drive System Options with Battery Backup and
Temperature Sensors (Rotation Alarm is already included with unit)
W348893V2 R2P 2.0 Roller Bottom Drive System Options with Battery Backup and
Temperature Sensors (Rotation Alarm is already included with unit)
Deck Kit For Modular Spaced Systems – The deck kit is designed for modular
systems with removable decks. These are kits designed for customer installation.
Deck Kit For Production Spaced Systems – The deck kit is designed for production
systems with removable decks. These are kits designed for customer installation.
Cat. No. Description Qty / Case
W348887 5 position deck, 7 1/8” Deck Spacing 1
W348889 5 position deck, 6 “ Deck Spacing 1
Please contact your WHEATON representative for information regarding retrofits,
modifications, custom systems and deck kits for existing systems.
Refer to page 189-190 for plug styles.
Top Mount Available
