WHEATON 2016 Lab Catalog

60 / 196

WHEATON 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | 856.825.1368 (F) |
Refer to page 189-190 for plug styles.
> 59 Cell Culture
Bench-Top Systems – Mini-Bottle
Additional Deck Kit
■ Allows for serum and media bottles as well as
culture tubes
■ For cell cultivation or staining procedures
■ Accommodates bottles 38 to 60mm in diameter
and 240mm long
■ Deck kits available to double or triple capacity
Cat. No. Plug Style Voltage Qty / Case
W348923-A North America 120 VAC 1
W348923-B Japan 100 VAC 1
W348923-C Continental Europe 230 VAC 1
W348923-D United Kingdom 230 VAC 1
W348923-F Australia / China 240 VAC 1
W348923-G Italy / Chile 230 VAC 1
W348923-J India 230 VAC 1
Cat. No. Description Qty / Case
W348920-CH Deck Kit for Mini Bottle Bench-Top Roller Rack 1
*Shown with Additional Deck Kit
Capacity:..................................................................................... 4-12 Positions
Bottle Speed:...............................................2-45 RPM (dependent on bottle size)
Bottle Diameter:..................................................................................38-60mm
Bottle Length:............................................................................... Up to 240mm
Weight:..............................................................................................18lb (8kg)
Dimensions: W x D X H...................... 12.25 x 12.75 x 7.125” (32 x 32.5 x 18cm)
Humidity:................................................................................. 80% up to 31°C
Operating Temperature:.....................................................................10 to 40°C
Electrical:............................................................. 100-240 VAC, 50/60 Hz, 14W
Specifications
■ Ideal for sensitive procedures or difficult
to reach areas
■ Same interface layout as Micro-Stir® and
BioStir® stirrers
■ Slim communication cord; no power
cord required
Remote Control Unit
■ Ideal for general mixing and difficult to dissolve solutes
■ 150-1200 RPM, single and four place units
■ Programmable, remote control and alarm capable
BioStir® Magnetic Stirrer
Cat. No. Description Qty / Case
W900702- [ ]* Single Place BioStir® 1
W900703- [ ]* Four Place BioStir ® 1
Micro-Stir ® Magnetic Stirrer & BioStir® Magnetic Stirrers
■ Ideal for low speed shear sensitive mixing
■ 5-200 RPM, single and four place units
■ Programmable, remote control and alarm capable
Micro-Stir® Magnetic Stirrer
Cat. No. Description Qty / Case
W900700- [ ]* Single Place Micro-Stir ® 1
W900701- [ ]* Four Place Micro-Stir ® 1
Electrical:
Operating Voltage:.........................................................100-240 VAC, 50/60 Hz
Power Consumption:............................................................................ 15 Watts
Pollution Degree:....................................................................................Class 2
Environmental:
Operating Temperature:................................................................... 15° to 40°C
Humidity:............................................................ 80% up to 31°C, 50% at 40°C
Altitude Limit:.........................................................................................2000m
Operating Speed:
Micro-Stir®...................................................................................... 5-200 RPM
BioStir® ..................................................................................... 150-1200 RPM
Maximum Flask Size:............................................................................ 3L Flask
Dimensions: H x W x D
Single Place:...............................................3.6 x 8 x 9.8” (9.2 x 20.3 x 24.9cm)
Four Place:............................................4 x 15.5 x 17.5” (10.2 x 39.4 x 44.5cm)
Weight:
Single Place:..................................................................................4.5lb (1.9kg)
Four Place:......................................................................................10lb (4.5kg)
Specifications
Cat. No. Description Qty / Case
W900704 Remote Control 1
