Cell Culture
Width
Depth
Height
Weight
Part Number
# Positions
# Decks
(in / cm)
(in / cm)
(in / cm)
(lb / kg)
# of Bottle Positions
Control System
Bottom Drive Production Spacing
WRBPR5010-A
5
1
31 / 79
25 / 63
14 / 35
52 / 24
5
R2P 2.0
WRBPR5030-A
5
3
31 / 79
25 / 63
26 / 65
85 / 39
15
R2P 2.0
WRBPF5110-A
5
11
31 / 79
25 / 63
74 / 187
217 / 99
55
R2P 2.0
WRBPF8110-A
8
11
47 / 120
25 / 63
74 / 187
360 / 167
88
R2P 2.0
Bottom Drive Modular Spacing
WRBMR5010-A
5
1
30 / 76
25 / 63
14 /34
70 / 32
5
R2P 2.0
WSBMR5010-A
5
1
30 / 76
25 / 63
14 /34
70 / 32
5
Standard
WRBMR5030-A
5
3
30 / 76
25 / 63
29 / 74
112 / 51
15
R2P 2.0
WSBMR5030-A
5
3
30 / 76
25 / 63
29 / 74
112 / 51
15
Standard
WRBMR5070-A
5
7
30 / 76
25 / 63
57 / 145
196 / 89
35
R2P 2.0
WSBMR5070-A
5
7
30 / 76
25 / 63
57 / 145
196 / 89
35
Standard
WRBMR5090-A
5
9
30 / 76
25 / 63
71 / 179
238 / 108
45
R2P 2.0
WSBMR5090-A
5
9
30 / 76
25 / 63
71 / 179
238 / 108
45
Standard
Top Drive Production Spacing
WRTPF5110-A
5
11
31 / 79
25 / 63
75 / 190
250 / 113
52
R2P 2.0
WSTPF5110-A
5
11
31 / 79
25 / 63
75 / 190
250 / 113
52
Standard
WRTPF8110-A
8
11
47 / 120
25 / 63
75 / 190
350 / 159
85
R2P 2.0
WSTPF8110-A
8
11
47 / 120
25 / 63
75 / 190
350 / 159
85
Standard
Part Numbers and Sizing Information for Most Common Systems
Ordering Information
WHEATON specializes in standard and customized roller apparatus units. The part numbering system below allows for the configuration of a standard system. The main components
that make up a unit include the control system, the size and type of roller bottle decks and system options. There is also a table below listing the most commonly used roller
apparatus. If you have any questions about custom bottle sizes, rotation speeds or standard systems do not hesitate to contact your WHEATON representative.
Refer to page 58 for
